Anti Aging 4KN 11KV Porcelain High Tension Insulator

500PCS
MOQ
Negotiated
Price
Anti Aging 4KN 11KV Porcelain High Tension Insulator
Features Gallery Product Description Request A Quote
Features
Specifications
Type: Insulator, Post Insulator
Material: Porcelain
Application: High Voltage
Rated Voltage: 11KV
Tensile Strength:: 4KV
Color: White, Brown
Highlight:

11KV High Tension Insulator

,

4KN High Tension Insulator

,

11KV Porcelain Insulator

Basic Infomation
Place of Origin: Ningbo,China
Brand Name: Suntech
Certification: ISO
Model Number: Post tension
Payment & Shipping Terms
Packaging Details: Exported Wooden Case or Containers
Delivery Time: 5-7 days after deposit
Payment Terms: L/C, T/T, Western Union
Supply Ability: 5000pcs per week
Product Description

11KV High Voltage Electrical Porcelain Post Tension Insulator



The composite insulator is a composite structure insulator composed of organic silicon rubber synthetic materials, which is mainly composed of hardware, umbrella skirt sheath, core rod, bonding layer and equalizing ring. The umbrella cover made of silicone rubber material is used to ensure the external insulation of the product, and the high-strength epoxy lead rod provides internal insulation of the product and bears the mechanical load. This kind of composite insulator is used to support and fix the bus bar and the live conductor. The specially designed umbrella skirt is used to increase the creepage distance, so that there is sufficient distance and insulation between the live conductor or between the conductor and the earth. It is in the transmission line It plays a major role in ensuring the use and operating life of the entire line. The company’s composite insulators adopt a new process of integral moulding of high-quality silicone rubber umbrella sleeves and integral crimping of core rods and hardware ends. It has superior mechanical properties, good pollution flashover resistance, excellent electrical corrosion resistance, and good aging resistance. High operating efficiency, light weight, and high reliability.


Precautions in installation:
1. The insulator should be handled with care in carrying or installing, to avoid It colliding and fracti. factioning with parts like the conductor. wiring board, tool as well as sharp material.
2. When the composte insulator Is hung, the rope should be tied at the end accessory (fitting), rather than the shed or sheath, If
the rope has to touch the shed and sheath, the contact part should be covered with the soft cloth.
3. Even if the material of the this insulator shed has the rat- repelling property. some rat-proof measures should be still taken
in the storing place just in case. The damaged shed should be rejected.


Packaging & Delivery

Quantity(Pieces) 1 - 1000 1001 - 5000 >5000
Est. Time(days) 35 45 To be negotiated
Anti Aging 4KN 11KV Porcelain High Tension Insulator 0

About us: Suntech Power Tools, which located in the southeast China, it is the earliest origin Power Tools Leading City in China.We are making the various related cable pulling tools, and hydraulic tension and puller to support the transmission work.All canaccept OEM and professionally produced per ISO 9001:2008, they are being sold to over more than 50 countries in the world,and has wined the best brand reputations. Some items like the stringing blocks,cable rollers,the cable jack stands,etc we can customized, and the Construction Safety Tools ,are not demanded the MOQ. You can freely help you out either
