Professional 6.3-9KW Double Drum Winch with 2000-3600RPM Speed for Simultaneous Cable Pulling and Tensioning in Power Line Work

1 PCS
MOQ
Negotiable
Price
Professional 6.3-9KW Double Drum Winch with 2000-3600RPM Speed for Simultaneous Cable Pulling and Tensioning in Power Line Work
Features Gallery Product Description Request A Quote
Features
Specifications
Name: Double Drum Winch
Model: JJCS
Power: 6.3-9KW
Speed: 2000-3600RPM
Drum Diameter: 230-300mm
Weight: 280-700KG
Highlight:

6.3-9KW Power Double Drum Winch

,

2000-3600RPM Speed Conductor Stringing Winch

,

Simultaneous Cable Pulling and Tensioning Power Line Winch
Basic Infomation
Place of Origin: Ningbo
Brand Name: Suntech
Certification: ISO
Model Number: JJCS
Payment & Shipping Terms
Packaging Details: Plywood Case
Delivery Time: 3-7days
Payment Terms: L/C,T/T
Supply Ability: 30000 PCS/Month
Product Description
Professional Double Drum Winch for Simultaneous Cable Pulling and Tensioning
Engineered for complex, heavy-duty tasks in electrical transmission, distribution, and utility construction, this sophisticated pulling machine features two independent rotating drums on a single chassis for simultaneous, independent line handling.
Technical Specifications
Item No. 09151 09152 09162
Model JJCS-50J JJQS-50J JJCS-50T
Engine Model KF186A Diesel Engine Honda 390 Gasoline Engine S195G Diesel Engine
Power (KW) 6.3 6.6 9
Speed (RPM) 2600 3600 2000
Pull Force (KN)/Speed (M/MIN) - Slow 50*6.0,30/10 50/6.0,30/10 50/3.1,40/9.6
Pull Force (KN)/Speed (M/MIN) - Moderate / / 45/7.1,17/22.3
Pull Force (KN)/Speed (M/MIN) - Fast 13/23,10/30 13/23,10/30 33/11.3,10/35.6
Reverse -/5,-/17 -/5,-/17 -/7.35
Drum Bottom of Groove Diameter Φ230 Φ230 Φ300
Outline Size (MM) 1280*770*600 1280*770*600 2440*1300*1140
Weight (KG) 280 270 700
Key Applications & Benefits
  • Continuous Tension Stringing for Overhead Lines: Enables precise installation of overhead power lines with controlled tension and sag throughout the entire pull, preventing ground contact and ensuring installation quality.
  • Efficient Bundle Conductor Installation: Essential for high-capacity transmission lines using multiple conductors per phase, allowing synchronized or sequential installation with consistent tension across all conductors.
  • Independent Control for Complex Scenarios: Two independently operating drums enable sophisticated maneuvers like controlled counter-tension to prevent snaking or kinking during cable pulls.
  • Enhanced Job Site Efficiency: Consolidates functions of two separate machines into one unit, reducing equipment transport and setup requirements while enabling continuous work cycles.
  • Superior Safety Features: Maintains constant control over cables to prevent dangerous slack lines, with remote operation capabilities that keep personnel at safe distances.
  • Long Distance & Aerial Installations: Ideal for installing long-span aerial cables, river crossings, and challenging terrain routes while maintaining consistent tension over kilometers.
  • Extreme Duty Construction: Built for harsh field conditions with heavy-duty gearboxes, high-capacity brakes, and robust drum assemblies for dependable performance.
  • Versatile Utility Applications: Suitable for underground cable pulling, cable recovery operations, and specialized lifting requiring independent line control.
  • Professional Contractor Equipment: Fundamental capital equipment for transmission and large-scale distribution work, enabling execution of major line construction projects.
  • Strategic Investment Advantage: Delivers return through faster project completion, reduced crew requirements, improved safety, and access to higher-value projects.
The Double Drum Winch transforms complex, labor-intensive pulling tasks into smooth, controlled, and highly productive operations. As the workhorse of modern overhead line construction and heavy cable pulling, it is indispensable for building and maintaining high-capacity electrical infrastructure for today's and tomorrow's energy needs.
