916 Series Stringing Block Customizable Overhead Transmission Line Tools For ACSR720 Conductor

1set
MOQ
Negotiable
Price
916 Series Stringing Block Customizable Overhead Transmission Line Tools For ACSR720 Conductor
Features Gallery Product Description Chat Now
Features
Specifications
Name: 916 Series Stringing Block
Item No.: 10151-10153
Sheave: 1/3/5
Rated Load: 50-150KN
Weight: 51-200KG
Sheave Features: MC Nylon Sheave
Highlight:

Overhead Transmission Line Stringing Block

,

ACSR720 Conductor Stringing Block

,

Customizable Stringing Block
Basic Infomation
Place of Origin: Ningbo, China
Brand Name: Suntech
Certification: ISO9001
Model Number: SHD916
Payment & Shipping Terms
Packaging Details: Wooden box
Delivery Time: 1-2 Weeks
Payment Terms: L/C, T/T
Supply Ability: 200units/month
Product Description

916 Series Stringing Block Customizable Overhead Transmission Line Tools for ACSR720 Conductor



About us: Suntech Power Tools, which located in the southeast China, it is the earliest origin Power Tools Leading City in China.We are making the various related cable pulling tools, and hydraulic tension and puller to support the transmission work.All canaccept OEM and professionally produced per ISO 9001:2008, they are being sold to over more than 50 countries in the world,and has wined the best brand reputations. Some items like the stringing blocks,cable rollers,the cable jack stands,etc we can customized, and the Construction Safety Tools ,are not demanded the MOQ. You can freely help you out either



1.Maximum suitable conductor ACSR720.

2.Sheave dimension ( outside diameter× root diameter × sheave width) Φ916×Φ800×110(mm).

3.The middle sheave can be customized as cast steel sheave

916mm Main Specifications

Item Number Model Number of Sheave Rated Load(KN) Weight(kg) Sheave Feature
10151 SHDN916 1 50 51 MC nylon sheave
10152 SHSQN916 3 75 120 MC nylon sheave
10153 SHWQN916 5 150 200 MC nylon sheave
10151 SHDN916-125 1 50 60 MC nylon sheave



916 Series Stringing Block Customizable Overhead Transmission Line Tools For ACSR720 Conductor 0
