Place of Origin: | Zhejiang, China |
Brand Name: | Suntech |
Certification: | ce iso |
Model Number: | JJM5BC |
Minimum Order Quantity: | 1set |
---|---|
Price: | Negotiate |
Packaging Details: | Exporting Cases |
Delivery Time: | 7-10days |
Payment Terms: | T/T |
Supply Ability: | 100pcs/Month |
Product Name: | Cable Pulling Winch | Motor: | Gasoline Or Diesel Engine |
---|---|---|---|
Capacity: | 10KW | Pulling Force: | 5T |
Site: | Construction | Application: | Transmission Line |
High Light: | Electrical Power Line 5 Ton Winch,Diesel Engine 5 Ton Winch,Construction High Speed Winch |
Cable Winch Puller 5 Ton Diesel Engine Fast Speed Winch Belt Driven Application
5 Ton Variable Speed Diesel Power Winch is used for tower erection,pole setting,stringing wire in electrical power line construction.
Diesel Winch can be modified as per requirement, such as changing curve capstan into straight even cylindrical shape and coming with steel rope.
Technical Data Cable Winch Puller 5 Ton Diesel Engine Fast Speed Winch Belt Driven
Model Type | Gear | Pulling Force(KN) | Pulling Speed(m/min) | Power(KW) | Weight(KG) |
JJM-5BC | Slow | 50 | 4.5 | 10 | 137 |
Fast | 25 | 8.5 | |||
Reverse | NO Lifting | 4 |
Features Cable Winch Puller 5 Ton Diesel Engine Fast Speed Winch Belt Driven
1) Speedy and Efficient
2) Safe and Reliable
3) Compact structure
4) Light Weight
5) Small Volume
6) Widely Used
Work principle engine powered winch
The winch transforms electric energy into mechanical energy through the motor1, which is rotor of the motor moves, outputs, and then through the brake 2,
and the reducer 3 reduces speed to rotate the reel 4. The reel winds the wire rope and passes through pulley block to make the hook lift the load Q,
and transforms mechanical energy into mechanical work finishing transportation, load and unload of heavy weights.
