Ningbo Suntech Power Machinery Tools Co., Ltd.
Professional Manufacturer and Exporter of Electric Power Field
 |
| Place of Origin: | Ningbo,China |
| Brand Name: | Suntech |
| Certification: | ISO,CE |
| Model Number: | JJD-5 |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Get newest price |
| Packaging Details: | Exported cartons or cases |
| Delivery Time: | 7-10 workdays |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 100 sets per month |
| Model: | JJD | Voltage: | 220v/380v |
|---|---|---|---|
| Electro Motor: | 4KW | Phase: | One Or Three |
| Application: | Transmission Line | Usage: | Cable Pulling |
| High Light: | 50KN Electric Cable Pulley Machine,Transmission Line Wire Pulling Tools 380V,380V Electric Cable Pulley Machine |
||
50KN 380V Electric Engine Cable Powered Winch for Pulling and Hoisting
Line Construction Tool Electric Engine Cable Pulling Winch for 5 Ton with 4KW Electromotor
Engine Powered Winch Application
Engine Powered Hoist Winch(With Rope) is used for tower erection, stringing in electric power line construction.
| Item number | Model | Rotation direction |
Gear | (RPM) rotational speed |
(M/MIN) Traction speed |
(T) Tractive force |
(KW) Power |
(MM) Outline size |
(KG) Weight |
| 09121 | JJQ-3Q 6HP Gasoline engine |
corotation | ⅠSlow | 9.0 | 4.0 | 3.0 | 4.04 | 840x450x500 | 82 |
| ⅡFast | 16.0 | 6.6 | 1.8 | 780x450x500 | 85 | ||||
| reversal | Reverse | 7.5 | 3.3 | No lifting | |||||
| 09121A | JJC-30 170F Diesel engine |
corotation | ⅠSlow | 11.5 | 5.0 | 3.0 | 2.94 | 840x600x500 | 108 |
| ⅡFast | 21.0 | 9.0 | 1.8 | ||||||
| reversal | Reverse | 10.0 | 4.5 | No lifting | |||||
| 09121B | JJD-30 3KWElectromotor |
corotation | ⅠSlow | 8.5 | 4.0 | 3.0 | 3.00 | 770x600x460 | 108 |
| ⅡFast | 10.5 | 6.5 | 1.8 | ||||||
| reversal | Reverse | 7.0 | 3.0 | No lifting | |||||
| 09123 | JJQ-50 9HP Gasoline engine |
corotation | ⅠSlow | 6.5 | 4.0 | 5.0 | 6.61 | 1000x550x520 | 135 |
| ⅡFast | 16.0 | 9.0 | 2.2 | ||||||
| reversal | Reverse | 7.0 | 4.0 | No lifting | |||||
| 09123A | JJC-50 6.6HPDiesel engine |
corotation | ⅠSlow | 8.0 | 4.5 | 5.0 | 4.41 | 1000x750x600 | 168 |
| ⅡFast | 19.0 | 11.0 | 2.3 | ||||||
| reversal | Reverse | 10.0 | 5.5 | No lifting | |||||
| 09123B | JJD-50 4KW Electromotor |
corotation | ⅠSlow | 5.5 | 3.5 | 5.0 | 4.00 | 1000x850x520 | 160 |
| ⅡFast | 14.0 | 8.0 | 3.0 | ||||||
| reversal | Reverse | 7.0 | 4.0 | No lifting | |||||
| 09125 | JJQ-80 13HP Gasoline engine |
corotation | ⅠSlow | 5 | 3 | 8 | 9.60 | 1000x550x520 | 168 |
| ⅡFast | 9 | 5 | 4.5 | ||||||
| reversal | Reverse | 5 | 3 | No lifting | |||||
| 09125A | JJC-80 10.5HP Diesel engine |
corotation | ⅠSlow | 7 | 4 | 8 | 7.86 |
1000x750x630 | 230 |
| ⅡFast | 13 | 7.5 | 4 | ||||||
| reversal | Reverse | 6.5 | 3.7 | No lifting |
