Manual Chain Hoist 5-200KN for Power Line Construction

1 PCS
MOQ
Get the newest price
Price
Manual Chain Hoist 5-200KN for Power Line Construction
Features Gallery Product Description Request A Quote
Features
Specifications
Name: Manual Chain Hoist
Item No.: 14282-14351
Rated Load: 5-200KN
Standard Lifting Height: 3M
Weight: 10-193KG
Weight Of 1m Chain: 1.7-19.4KG
Highlight:

Overhead ACSR Aluminum Conductor Cable

,

Aluminum Conductor Cable 175mm2

,

Power Transmission Overhead Aluminum Wire
Basic Infomation
Place of Origin: Ningbo,China
Brand Name: Suntech Power
Certification: ISO9001,CCC
Model Number: Manual
Payment & Shipping Terms
Packaging Details: Plywood Case
Delivery Time: 3-7days
Payment Terms: L/C,T/T
Supply Ability: 3000 PCS/Month
Product Description
Professional Manual Chain Hoist For Power Line Construction
Attribute Value
Name Manual Chain Hoist
Item No. 14282-14351
Rated Load 5-200KN
Standard Lifting Height 3M
Weight 10-193KG
Weight of 1m Chain 1.7-19.4KG
Product Introduction
  • Essential lifting equipment for power line installation and maintenance
  • Manual chain operation provides precise load control
  • Trusted solution by utility professionals worldwide
Key Features
  1. Precision Lifting
    • Smooth gear operation for accurate positioning
    • Positive load control at all times
  2. Robust Construction
    • High-grade alloy steel gears
    • Reinforced load chain for heavy-duty use
  3. Safety Features
    • Automatic braking system
    • Overload protection mechanism
  4. Operational Efficiency
    • Ergonomic hand chain design
    • Easy chain length adjustment
  5. Durability Advantages
    • Zinc-plated corrosion protection
    • Replaceable wear components
Typical Applications
  • Transmission tower assembly
  • Substation equipment installation
  • Temporary cable support
  • Emergency repair operations
Workflow Integration
  • Compatible with standard rigging hardware
  • Works with various lifting slings
  • Integrates with load monitoring systems
Maintenance Benefits
  • Self-lubricating mechanism
  • Easy visual inspection process
  • Minimal maintenance requirements
User Guidelines
  1. Pre-Operation
    • Inspect chain and hooks thoroughly
    • Verify proper load rating
  2. During Use
    • Maintain steady lifting speed
    • Monitor load position constantly
  3. Post-Use
    • Clean after dirty conditions
    • Store in dry environment
Industry Compliance
  • Meets ASME B30.21 standards
  • OSHA compliant for construction
  • Certified by major utilities
Why Professionals Choose Us
  • 35% smoother operation than competitors
  • 45% more durable than standard hoists
  • 1-year gear mechanism warranty
Customer Support
  • Free product training videos
  • 24/7 technical assistance
  • Replacement parts inventory
Purchasing Options
  • Single units or crew sets
  • Custom configurations available
  • Volume discounts for utilities
Item No. 14282 14292 14302 14312 14321 14331 14341 14351
Rated load(KN) 5 10 15 20 30 50 100 200
Minimum distance between hooks(MM) 280 320 390 410 485 600 820 1040
Standard lifting height(M) 3
Number of lines of lifting chain(row) 1 1 1 1 2 2 4 8
Net weight(KG) 10 12 19 20 27 45.5 83 193
Item No. Lifting height(4M) 14283 14293 14303 14313 14322 14332 14342 14352
Lifting height(5M) 14284 14294 14304 14314 14323 14333 14343 14353
Lifting height(6M) 14285 14295 14305 14315 14324 14334 14344 14354
Lifting height(8M) / / / / 14325 14335 14345 14355
Lifting height(10M) / / / / 14326 14336 14346 14356
Weight of 1M chainKG 1.7 1.7 2.3 2.3 3.7 5.6 9.7 19.4
