Dual-Hook Steel Turnbuckle 5-100KN for Power Line Construction

1 PCS
MOQ
Get the newest price
Price
Dual-Hook Steel Turnbuckle 5-100KN for Power Line Construction
Features Gallery Product Description Request A Quote
Features
Specifications
Name: Dual-Hook Steel Turnbuckle
Item No.: 14111-14117
Model: SJS-0.5-SJS-10
Rated Load: 5-100KN
Max Centere Distance: 800-1740mm
Weight: 2.5-10KG
Highlight:

Electric Cable Bare Conductor

,

Overhead Bare Aluminium Conductor

,

Steel Reinforced Bare Aluminum Wire
Basic Infomation
Place of Origin: Ningbo,China
Brand Name: Suntech Power
Certification: ISO9001
Model Number: SJS-1
Payment & Shipping Terms
Packaging Details: Plywood Case
Delivery Time: 3-5days
Payment Terms: L/C,T/T
Supply Ability: 4000 PCS/month
Product Description
Professional Dual Hook Steel Turnbuckle For Power Line Construction
Product Specifications
Attribute Value
Name Dual-Hook Steel Turnbuckle
Item No. 14111-14117
Model SJS-0.5-SJS-10
Rated Load 5-100KN
Max Center Distance 800-1740mm
Weight 2.5-10KG
Product Introduction
  • Essential tensioning device for power line installations
  • Dual-hook design provides secure connections
  • Trusted solution by utility contractors nationwide
Key Features
  • Dual Hook System - Positive locking hook design prevents accidental disengagement
  • Robust Construction - Forged steel body withstands heavy loads with reinforced threading for durability
  • Corrosion Protection - Hot-dip galvanized finish suitable for harsh environments
  • Safety Assurance - Clearly marked load ratings with fail-safe locking mechanism
  • Operational Efficiency - Tool-free length adjustment with smooth thread operation
Typical Applications
  • Transmission line tensioning
  • Guy wire installations
  • Temporary cable securing
  • Emergency repair work
Technical Specifications
Item number Model Rated load (kN) Maximum center distance Adjustable distance (mm) Weight (kg) Remark
14111 SJS-0.5 5 800 300 2.5 Steel
14112 SJS-1 10 860 250 3.5
14113 SJS-2 20 1050 340 4
14114 SJS-3 30 1350 470 6
14115 SJS-5 50 1440 510 8
14116 SJS-8 80 1670 560 8.5
14117 SJS-10 100 1740 600 10
Dual-Hook Steel Turnbuckle 5-100KN for Power Line Construction 0
Industry Compliance
  • Meets ASTM A489 standards
  • OSHA compliant for construction
  • Certified by major utilities
Why Professionals Choose Us
  • 40% stronger than standard turnbuckles
  • 30% faster adjustment than competitors
  • 1-year structural warranty
