Integral Hydraulic Cable Cutter CC-50A 100KN for Power Lines

1 PCS
MOQ
Negotiation
Price
Integral Hydraulic Cable Cutter CC-50A 100KN for Power Lines
Features Gallery Product Description Request A Quote
Features
Specifications
Name: Integral Hydraulic Cable Cutter
Item No.: 21447A-21447F
Model: CC-50A
Crimping Force: 70-100KN
Stroke: 40-85mm
Weight: 8.9-13KG
Highlight:

Bare ACSR Aluminum Conductor

,

Steel Reinforced Bare Overhead Conductors

,

397.5 MCM All Aluminum Conductor
Basic Infomation
Place of Origin: Ningbo,China
Brand Name: Suntech
Certification: ISO9001,CCC
Model Number: CC-50A
Payment & Shipping Terms
Packaging Details: Plywood Case
Delivery Time: 3-7days
Payment Terms: L/C,T/T
Supply Ability: 2000 PCS/month
Product Description
Professional Integral Hydraulic Cable Cutter For Power Line Construction
Product Specifications
Attribute Value
Name Integral Hydraulic Cable Cutter
Item No. 21447A-21447F
Model CC-50A
Crimping force 70-100KN
Stroke 40-85mm
Weight 8.9-13KG
Product Overview

Essential hydraulic cutting tool for power line installation and maintenance, featuring an integrated hydraulic system for powerful and precise cutting. Trusted by utility professionals for heavy-duty cable cutting operations.

Key Features
Hydraulic Cutting Power
  • Self-contained hydraulic system
  • Consistent cutting force up to 20 tons
Robust Construction
  • Forged steel blades for maximum durability
  • Reinforced pivot mechanism
Safety Assurance
  • Non-conductive fiberglass handles
  • Automatic pressure relief valve
Precision Cutting
  • Laser-cut hardened steel blades
  • Clean cuts without cable deformation
Operational Efficiency
  • One-handed operation capability
  • Quick-release valve for fast reset
Applications
  • Overhead transmission line cable cutting
  • Underground power cable termination
  • Substation wiring modifications
  • Emergency cable repairs
Technical Specifications
Item number 21447A 21447B 21447C
Model CC-50A CPC-50A HT-50A
Crimping force 100KN 80KN 70KN
Cutting range CU/AL cable Φ50mm max
ACSR cable Φ50mm max
Armored CU/AL cable Φ50mm max		 Steel rope cable Φ18mm max
Steel strand Φ10mm max
ACSR cable Φ50mm max		 Steel rope cable Φ15mm max
Strand Φ16mm max
Armored CU/AL cable Φ50mm max
Stroke 50mm 50mm 40mm
Length approx.620mm approx.620mm approx.660mm
Weight approx.N.W6.1KG G.W9.1KG approx.N.W6.2KG G.W9.2KG approx.N.W6.5KG G.W8.9KG
Package plastic box plastic box plastic box
Item number 21447D 21447E 21447F
Model CPC-40FR CPC-50FR CPC-85FR
Crimping force 70KN 80KN 80KN
Cutting range Steel rope cable Φ18mm max
ACSR cable Φ40mm max
Armored CU/AL cable Φ40mm max
Steel strand Φ16mm max		 Steel rope cable Φ18mm max
ACSR cable Φ50mm max
Armored CU/AL cable Φ50mm max
Strand Φ16mm max		 Armored CU/AL cable Φ85mm max
Stroke 40mm 50mm 85mm
Length approx.700mm approx.710mm approx.820mm
Weight approx.N.W6KG G.W9KG approx.N.W7KG G.W10KG approx.N.W9.5KG G.W13KG
Package plastic box plastic box steel case
Product Image
Integral Hydraulic Cable Cutter CC-50A 100KN for Power Lines 0
