Engineered Tubular A-Frame for Transmission Tower Construction

Features:
The A-Shape Tubular Gin Pole is a heavy-duty lifting system designed for stability and high load capacity in transmission tower construction and maintenance. Its tubular A-frame structure provides superior strength and features:

High-grade steel or aluminum construction with optional galvanization for corrosion resistance

Wide base configuration for enhanced stability during lifts

Integrated rigging points for secure load attachment

Smooth inner cable guides to reduce friction and wear

Optional load monitoring system with digital readout

Quick-connect hardware for fast assembly and disassembly

Working Principle:
The A-frame base is anchored to a stable foundation or tower structure

Guy wires (when used) provide additional lateral support

A hoisting mechanism (manual or powered) is mounted at the apex

The load is lifted vertically between the two legs of the A-frame

Guiding rollers ensure controlled movement and prevent swinging

Applications:
Transmission tower erection and maintenance

High-voltage line installation and stringing

Substation equipment lifting

Telecommunication tower assembly

Bridge cable and structural installations

Advantages:
✔ Exceptional Stability – A-frame design resists tipping and side loads
✔ Higher Load Capacity – Supports heavier weights than single-pole systems
✔ Precision Control – Ideal for aligning large tower components
✔ Durable Construction – Weather-resistant materials for long-term use

Service & Support:
Engineered load calculations for specific project requirements

Custom fabrication available for unique applications

Comprehensive inspection and maintenance guidelines
