Hydraulic Type Cable Reel Stand High Efficiency Reel Support For Grid Projects​

Hydraulic Type Cable Reel Stand High Efficiency Reel Support For Grid Projects​

Core Design Features​​

• ​​Heavy-duty hydraulic lifting system​​ with 10-ton capacity (20-ton overload protection)
• ​​Steel reinforced frame​​ with powder-coated finish for corrosion resistance
• ​​Adjustable reel arms​​ accommodate 600-2500mm diameter cable drums
• ​​360° rotating platform​​ with low-friction bearing system
• ​​Dual hydraulic cylinders​​ for balanced lifting force distribution
• ​​Built-in pressure gauge​​ for real-time load monitoring

​​Operational Advantages​​
✔ ​​One-person operation​​ with ergonomic hydraulic pump handle
✔ ​​Precision height adjustment​​ (50-1500mm lifting range)
✔ ​​Smooth rotation​​ reduces cable payout resistance by 60%
✔ ​​Quick-release mechanism​​ for fast drum changes (<1 minute)
✔ ​​Stabilizing outriggers​​ prevent tipping during operation

​​Hydraulic System Specifications​​
• ​​Working pressure:​​ 70MPa
• ​​Pump oil capacity:​​ 2.5L (ISO VG 46 hydraulic oil)
• ​​Cylinder stroke:​​ 1000mm
• ​​Emergency manual lowering valve​​ for power failure situations

​​Safety Features​​
✓ ​​Automatic pressure relief valve​​ (set at 110% max load)
✓ ​​Mechanical locking pins​​ at 5 height positions
✓ ​​Non-slip rubber pads​​ on all contact surfaces
✓ ​​High-visibility safety markings​​ on moving parts

​​Maintenance Requirements​​

• ​​Monthly inspection​​ of hydraulic hoses and connections
• ​​Quarterly oil change​​ (or every 500 operating hours)
• ​​Annual rebuild​​ of hydraulic cylinders
• ​​5-year structural integrity inspection​​

​​Typical Applications​​
➔ ​​High-voltage cable drum handling​​
➔ ​​OPGW fiber optic cable installation​​
➔ ​​Substation cable pulling operations​​
➔ ​​Underground cable deployment​​
➔ ​​Emergency power restoration work​
