Polygon Telecom Tower Telescoping Antenna Mast Transmission Line Steel Pole
Tower Fabrication
As outlined throughout our company profile, we have the in-house fabrication facilities to manufacture complete series of telecom tower ,monopole ,landscape monopole,
camouflage tree monopole ,self-supporting tower,RDS(rapid deployment sites),and camouflage antenna(air-conditioner;chinmey;water tank) with quick delivery at competitive
prices. Let us provide you a quotation.
Tower Design
Tell us your requirements and we will design and detail a complete antenna support structure to meet your needs. All tower design is done in complete
conformance with the latest revision of Telecommunications Industries Association standard TIA/EIA-222-G/F, “Structural Standards for Steel Antenna and Antenna Supporting Structures” and other industry standards, as applicable.
Design and Detailing
We have broad experience with virtually every make and model of tower used in the South America and Africa. Because of this, we can design and detail antenna mounts and other tower appurtenances to meet any needs and to fit any tower. With an in-house fabrication facility, we can custom-manufacture the items under our close scrutiny
to deliver what you need.
Structure Analysis and Calculation
We provides exceptional structural analysis services. A structural analysis goes deeper than just a visual inspection. The visual inspection
of a tower will show the physical condition of a tower such as rusting, cracking of welds, bent members, etc. but it will not show whether a tower is
overstressed by the loads it is supporting. A structural analysis uses mathematical engineering formulas for stress, along with known behavior of different materials under stress, to determine if any one point on the tower is stressed beyond safe limits. By using state-of-the-art computer software, we can create a mathematical model of any steel structure, and quickly determine the stresses at hundreds of points on the tower.
Telecom Structure Erection Guide
If you have any questions on tower structure erection ,pls feel free to contact us ,we can guide you how to erect the tower structure step by step ,we also can make the tower structure erection Assembly drawing and assembly instruction .so it will help you out on tower Structure erection easily.
| Height |
From 10M-100M or according to client’s requirement |
| Suit for |
Electric Power Transmission and Distribution |
| Shape |
Polygonal or Conical |
| Material |
Normally Q235B/A36,Yeild Strength≥235MPa |
| Q345B/A572,Yeild Strength≥345MPa |
| As well as Hot Rolled coil from ASTM572, GR65,GR50,SS400 |
| Power Capacity |
10kV to 500kV |
| Tolerance of the dimension |
According to client’s requirement |
| Surface treatment |
Hot-dip-galvanized following ASTM123, or any other standard by client’s requirement |
| Joint of Poles |
Slip joint, flanged connected |
| Standard |
ISO9001:2008 |
| Length of per section |
Within 13M once forming |
| Welding Standard |
AWS(American Welding Society)D 1.1 |
| Production Process |
Raw material test-cutting-bending-welding-dimension verify-flange welding-hole drilling-sample assemble-surface clean-galvanization or power coating /painting-recalibration-packages |
| Packages |
Packing with plastic paper or according to client’s requirement |
| Life Period |
More than 30 years |
