Steel Antenna Poles Towers Monopole Tower For Broadcasting / Cell Phone Signal
Signal tower is a type of signal transmission tower, also called a signal transmission tower or a signal
tower. Its main function is to support signal transmission and to support signal transmission antennas.
There are the following communication towers: angle steel four-post communication tower, steel pipe
three-post communication tower, single-pole communication tower (beautified, bionic tree, light pole),
lifting communication tower, and movable communication tower.
Product Description
| Product Name |
Steel Antenna Microwave Communication Monopole Tower For Broadcasting/ 4G /Cell Phone Signal |
Application |
• GSM
• WIFI
• Microwave
• Broadcasting |
| Material |
Q235B (SS400)
S355
Q345B(ASTM A572 Gr.50) |
Shape |
» Conical
» Octagonal
» Tapered round |
| Thickness |
4mm-30mm |
Installation
Method
|
Frange Connection
/ Direct Buried |
| Surface Treatment |
Hot Dip Galvanization/
Powder Coating
|
H.D.G. Standard |
GB/T 13912-2002
or ASTM A 123 |
| Welding Standard |
GBT 12467.2-2009
/ AWS D 1.1
/ BS EN 1011-1 |
Install Method
Of The Pole |
Slip Joint
/Base Plate
|
| Package |
Nude Packing or
Customized
|
Service Life Of
The Poles
|
More than 30 Years |
With more than 25 years experiences on the steel pole,we have manufactured and exported huge quantity
of hot dip galvanized and /or Steel Antenna Microwave Communication Monopole from 20m to 40m which
service for the signal transmission industry development of the world.We have the complete production line
and machines,and skillful workers with high efficiency which can make us produce 10 tons or 5 sets of the
electric power poles everyday. A quick production period and delivery schedule ensured our client have more
obvious advantage in their market.
The Steel Antenna Microwave Communication Monopole is made by the high-quality hot rolled steel plate
which was bent into Trapezoid according to the poles's dimension,then welding ,grinding,hot dip galvanized
and packing for delivery as following shows:
1. The single-tube tower is generally divided into 2-5 sections, which are connected by plug or flange.
2. The cross section of the single-tube tower is circular or polygonal, the main body of the tower is tapered,
and the upper diameter is small and the diameter is large.
3. There is an antenna installation platform on the body of the single-tube tower. The tower has a nail-climbing
worker to operate on the upper and lower towers. The tower has safety protection devices to protect workers.
4. Single-tube tower ladders can be set up in two forms: outer ladder and inner ladder.
5. The single-tube tower has a small footprint, simple tower structure and short construction period, which can
save land resources and costs, and is especially suitable for construction in cities.
Design and Detailing
We have broad experience with virtually every make and model of tower used in the South America and Africa.
Because of this, we can design and detail antenna mounts and other tower appurtenances to meet any needs
and to fit any tower. With an in-house fabrication facility, we can custom-manufacture the items under our close
scrutinyto deliver what you need.
Structure Analysis and Calculation
We provides exceptional structural analysis services. A structural analysis goes deeper than just a visual
inspection. The visual inspection
of a tower will show the physical condition of a tower such as rusting, cracking of welds, bent members, etc.
but it will not show whether a tower is
overstressed by the loads it is supporting. A structural analysis uses mathematical engineering formulas
for stress, along with known behavior of different materials under stress, to determine if any one point on
the tower is stressed beyond safe limits. By using state-of-the-art computer software, we can create a
mathematical model of any steel structure, and quickly determine the stresses at hundreds of points on the tower.
Telecom Structure Erection Guide
If you have any questions on tower structure erection ,pls feel free to contact us ,we can guide you
how to erect the tower structure step by step ,we also can make the tower structure erection Assembly
drawing and assembly instruction .so it will help you out on tower Structure erection easily
