Home /Products/Anti Twist Wire Rope/Dynema Rope 4-18mm for Power Transmission Line Construction

Dynema Rope 4-18mm for Power Transmission Line Construction

1 PCS
MOQ
Negotiation
Price
Dynema Rope 4-18mm for Power Transmission Line Construction
Features Gallery Product Description Request A Quote
Features
Specifications
Name: Dynema Rope
Diameter: 4-18mm
Linear Density: 9.31-186G/M
Sheath Diameter: 5.5-21mm
Break Force: 16.6-296KN
Warranty: 1 Year
Highlight:

750KV Power Transmission Galvanized Lattice Tower

,

10KV Power Transmission Galvanized Lattice Tower

,

Galvanized 10KV Power Transmission Tower
Basic Infomation
Place of Origin: China
Brand Name: Suntech
Certification: ISO9001
Model Number: Dynema
Payment & Shipping Terms
Packaging Details: Plywood Case
Delivery Time: 3-6days
Payment Terms: L/C,T/T
Supply Ability: 4000 PCS/Month
Product Description
Professional Dynema Rope For Power Transmission Line Construction
Product Specifications
Attribute Value
Name Dynema Rope
Diameter 4-18mm
Linear density 9.31-186G/M
Sheath diameter 5.5-21mm
Break force 16.6-296KN
Warranty 1 year
Product Introduction
  • Advanced synthetic rope solution for power industry applications
  • Ultra-high molecular weight polyethylene construction
  • Essential for safe and efficient power line operations
Key Features
  • Exceptional Strength: 15x stronger than steel at equivalent weight, maintains integrity under heavy loads
  • Lightweight Advantage: Floats on water, easy to handle and transport
  • Weather Resistance: UV stabilized for outdoor use, resists moisture and chemicals
  • Safety Benefits: Non-conductive for live work, high visibility colors available
  • Durability Features: Abrasion resistant outer coating, long service life
Technical Specifications
Diameter (MM) Linear density (G/M) Sheath diameter (MM) Break force (KN)
4 9.31 5.5 16.6
6 20 8 31.9
8 35 10 58.8
10 56 12 92.5
12 84 14 137
14 106 16 180
16 132 18 211
18 186 21 296
Typical Applications
  • Transmission line stringing operations
  • Substation equipment lifting
  • Temporary guy wire installations
  • Emergency restoration work
Workflow Integration
  • Compatible with standard rigging hardware
  • Works with tension monitoring systems
  • Integrates with pulling equipment
Maintenance Advantages
  • Requires minimal maintenance
  • Easy to clean and inspect
  • Resistant to mildew and rot
User Guidelines
  • Pre-Use Inspection: Check for surface damage, verify load requirements
  • During Operation: Avoid sharp edge contact, monitor for abrasion
  • Post-Use Care: Clean when dirty, store properly coiled
Industry Compliance
  • Meets OSHA standards
  • Certified for utility use
  • Complies with ANSI rope standards
Why Professionals Choose Us
  • 30% stronger than comparable ropes
  • 50% lighter than steel cables
  • 1-year performance guarantee
Customer Support
  • Free application consultation
  • 24/7 technical assistance
  • Custom length cutting service
Purchasing Options
  • Standard lengths or custom cuts
  • Bulk spool discounts
  • Fast delivery options
