Ningbo Suntech Power Machinery Tools Co., Ltd.
Professional Manufacturer and Exporter of Electric Power Field
 |
| Place of Origin: | Ningbo,Zhejiang,China |
| Brand Name: | Suntech |
| Certification: | ISO |
| Model Number: | 10mm Nylon Rope |
| Minimum Order Quantity: | 1000m |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Steel Drum or others |
| Delivery Time: | 15days after deposit |
| Payment Terms: | T/T, L/C, Western Union, MoneyGram |
| Supply Ability: | 200000meter/month |
| Item: | 10mm | Name: | Construction Nylon Rope |
|---|---|---|---|
| Type: | Nylon Traction Rope | Breaking Force: | More Than 920N |
| Linear Density: | 61 G/M | Material: | Rope Nylon |
| High Light: | Pressure Proof Insulated Nylon Wire Rope,92.5kN Nylon Wire Rope,10mm Insulated Wire Rope |
||
Power Line Nylon Rope Manufacturing , Heavy Duty Nylon Wire Rope Guide
Ningbo Suntech Power Material Tools Co.,Ltd. is a professional manufacturer of transmission line stringing tools and equipments in Ningbo,China.Our main products includes conductor stringing blocks,cable roller,hoisting tackles,pulley blocks,conductor grippers,cable reel stand,gin poles,inspection trolleys,hydraulic puller tensioner,conductor compressors,cable pulling winch,anti twisting wire steel rope,etc
Feature
1. The material is high strength fiber.
2. High strength and light in weight, flexible and easy in using
3. Pressure-proof and insulated, the most suitable rope for hot-line work
Our Values
1, Take First-Class Quality as Target and First-class Service.
2, As Responsibility, To Succeed By Scientific Management.
3, Customer in Heart, Quality in Hand, Technology in the Lead.
| Diameter(MM) |
Linear density(G/M) |
Linear density(G/M) |
Linear density(G/M) |
Break force(KN) |
| 4 | 9.31 | 5.5 | 13 | 16.6 |
| 6 | 20 | 8 | 28.2 | 31.9 |
| 8 | 35 | 10 | 48.4 | 58.8 |
| 10 | 56 | 12 | 77 | 92.5 |
| 12 | 84 | 14 | 113.4 | 137 |
| 14 | 106 | 16 | 150 | 180 |
| 16 | 132 | 18 | 177 | 211 |
| 18 | 186 | 21 | 247.3 | 296 |
Contact Person: Peter
Tel: 86-13958364836
