Ningbo Suntech Power Machinery Tools Co., Ltd.
Professional Manufacturer and Exporter of Electric Power Field
 |
| Place of Origin: | Ningbo,China |
| Brand Name: | Suntech |
| Certification: | ISO |
| Model Number: | Pilot Wire |
| Minimum Order Quantity: | 500m |
|---|---|
| Price: | Get The Latest Price |
| Packaging Details: | Steel Reels |
| Delivery Time: | 7-10 days after payment |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 20000 meter per day |
| Application: | Overhead Line Tranmission | Material: | Steel Wire |
|---|---|---|---|
| Item: | Hexagon 12 Strands Galvanized Anti Twisting Steel Wire Rope Pilot Rope | Struction: | Hexagon With 12 Strands |
| Diameter: | 10-30mm | Surface Treatment: | Galvanized |
| High Light: | Galvanized Anti Twist Wire Rope,Hexagon Anti Twist Wire Rope,12 Strands Galvanized Wire Rope |
||
Application
Hexagon 12 Strands Galvanized Anti Twisting Steel Wire Rope Pilot Rope is applied to mechanical pulling and tensioning release conductors.
Anti-twisting braided wire rope with high strength hot dip galvanized steel quality air processed by the special process of special woven rope line. It has high strength, good flexibility, corrosion rust-proof, not to fight the golden hook, and difficult to tie, long life and so on. Tension applied to pay-off power lines construction, lifting equipment with the balance shaft and the tail rope of mine, port and other major lift crane wire rope does not rotate when the required place.
Technical Data
We adopt high quality steel rope to braide anti-twisting steel rope.It is used for pulling the conductor in the overhead transmission line.
| Item no. | Normal Diameter (mm) | Structure | Ref. Weight (kg/m) | Breakage tension(kN) | ||
| Rope structure | ||||||
| 1x19 | 1x19W | T25 T29 | ||||
| YL9-12x19 | 10 | 6 Squares 12 Strands | 0.297 | 50 | 55 | |
| YL11-12x19 | 11 | 6 Squares 12 Strands | 0.480 | 70.5 | 80 | |
| YL13-12x19 | 13 | 6 Squares 12 Strands | 0.630 | 105 | 120 | |
| YL15-12x19 | 15 | 6 Squares 12 Strands | 0.925 | 140 | 158 | |
| YL18-12x19 | 18 | 6 Squares 12 Strands | 1.150 | 185 | 210 | |
| YL20-12x19 | 20 | 6 Squares 12 Strands | 1.320 | 250 | ||
| YL22-12XT25 | 22 | 6 Squares 12 Strands | 1.822 | 320 | ||
| YL24-12xT25 | 24 | 6 Squares 12 Strands | 2.034 | 360 | ||
| YL28-12xT29 | 28 | 6 Squares 12 Strands | 2.882 | 480 | ||
| YL30-12xT29 | 30 | 6 Squares 12 Strands | 3.120 | 540 | ||
| YL20-18x19 | 20 | 6 Squares 18 Strands | 1.598 | 280 | 300 | |
| YL22-18XT25 | 22 | 6 Squares 18 Strands | 1.898 | 389 | ||
| YL24-18xT25 | 24 | 6 Squares 18 Strands | 2.162 | 440 | ||
| YL28-18xT29 | 28 | 6 Squares 18 Strands | 3.012 | 580 | ||
| YL30-18xT29 | 30 | 6 Squares 18 Strands | 3.616 | 658 | ||
| Item no. | Normal Diameter (mm) | Structure | Standard Length (m) |
Diameter of spool (mm) |
Empty spool weight (kgs) |
| YL9-12x19 | 10 | 6 Squares 12 Strands | 1000 | ||
| YL11-12x19 | 11 | 6 Squares 12 Strands | 1000 | 1100x560 | 50 |
| YL13-12x19 | 13 | 6 Squares 12 Strands | 1000 | 1100x560 | 52 |
| YL15-12x19 | 15 | 6 Squares 12 Strands | 1000 | 1250x560 | 60 |
| YL18-12x19 | 18 | 6 Squares 12 Strands | 1000 | 1400 | 74 |
| YL20-12x19 | 20 | 6 Squares 12 Strands | 1000 | 1400 | 74 |
| YL22-12XT25 | 22 | 6 Squares 12 Strands | 800 | 1400 | 74 |
| YL24-12xT25 | 24 | 6 Squares 12 Strands | 800 | ||
| YL28-12xT29 | 28 | 6 Squares 12 Strands | 500 | ||
| YL30-12xT29 | 30 | 6 Squares 12 Strands | 500 | ||
| YL20-18x19 | 20 | 6 Squares 18 Strands | 1000 | ||
| YL22-18XT25 | 22 | 6 Squares 18 Strands | 500 | ||
| YL24-18xT25 | 24 | 6 Squares 18 Strands | 500 | ||
| YL28-18xT29 | 28 | 6 Squares 18 Strands | 500 | ||
| YL30-18xT29 | 30 | 6 Squares 18 Strands | 500 |
