CP-180 Manual Hydraulic Pump Hydraulic Crimping Tools

Negotiable
MOQ
Negotiable
Price
CP-180 Manual Hydraulic Pump Hydraulic Crimping Tools
Features Gallery Product Description Request A Quote
Features
Specifications
Structure: Multistage Pump, Multistage Pump
Usage: Power Construction
Application: Oil, Other, Provide Power
Fuel: Gasoline, No.15 Antiwear Hydraulic Oil
Pressure: High Pressure
Product Name: High Pressure Hydraulic Pump
Engine: Gasoline, No.15 Antiwear Hydraulic Oil
Power: Hydraulic
Weight: Approx.N.W9.5KG
Type: Hydraulic Tools
Highlight:

hydraulic hose crimping tool

,

CP-180 Hydraulic Crimping Tools

,

CP-180 Manual Hydraulic Pump
Basic Infomation
Place of Origin: Ningbo,China
Brand Name: Donghuan
Certification: ISO9001
Model Number: CP-700
Payment & Shipping Terms
Packaging Details: Export Carton or Ply-wood pallet
Delivery Time: 25 days after order confirmed
Payment Terms: T/T 30% as deposit,balance before delivery time
Supply Ability: 300pcs per month
Product Description

Light weight And Compact Design High Pressure Manual Hydraulic Pump



Manual Hydraulic Pump Application

to provide power for the cutting tool, the hydraulic compressor,

punching machine and other construction machinery,

which is operated in the wild field in electric power, railway, rescue, construction and other industries.



Manual Hydraulic Pump Features

1. Double loop piston
2. Iron box packing
3. Use No.15 Antiwear hydraulic oil



Manual Hydraulic Pump Specificaitons
Item number 16164C 16164 16164A 16164B
Model CP-180 CP-700 CP-700A CFP-800B
Type hand hand hand foot pump

Max output

pressure

 / low pressure 2Mpa low pressure 2Mpa low pressure 2Mpa
high pressure 70MPa high pressure 70Mpa high pressure 70Mpa high pressure 70Mpa

Output of

the oil

 / low pressure 13cc low pressure 13cc low pressure 13cc
high pressure 1.8cc high pressure 2.3cc high pressure 2.3cc high pressure 2.3cc
Oil capacity 350cc 900cc 2700cc 600cc

Direction

of piston

 single double double double
Weight(KG)

approx.N.W9.5KG

G.W10.9KG

approx.N.W9.5KG

G.W10.9KG

approx.N.W14.1KG

G.W15.5KG

approx.N.W9.8KG

G.W10.8KG

Measurement

(LxWxH)

 340×60×120mm 700x100x160mm 700x100x200mm 520x160x170mm
Package paper box paper box paper box paper box



CP-180 Manual Hydraulic Pump Hydraulic Crimping Tools 0CP-180 Manual Hydraulic Pump Hydraulic Crimping Tools 1CP-180 Manual Hydraulic Pump Hydraulic Crimping Tools 2CP-180 Manual Hydraulic Pump Hydraulic Crimping Tools 3CP-180 Manual Hydraulic Pump Hydraulic Crimping Tools 4CP-180 Manual Hydraulic Pump Hydraulic Crimping Tools 5
