916mm ACSR MC Nylon Conductor Wire Rope Stringing Pulley Blocks

916mm ACSR MC Nylon Conductor Wire Rope Stringing Pulley Blocks

  • 916mm ACSR MC Nylon Conductor Wire Rope Stringing Pulley Blocks
  • 916mm ACSR MC Nylon Conductor Wire Rope Stringing Pulley Blocks
  • 916mm ACSR MC Nylon Conductor Wire Rope Stringing Pulley Blocks
  • 916mm ACSR MC Nylon Conductor Wire Rope Stringing Pulley Blocks
916mm ACSR MC Nylon Conductor Wire Rope Stringing Pulley Blocks
Product Details:
Place of Origin: Fenghua,Zhejiang,China
Brand Name: Suntech
Certification: CE,SGS
Model Number: 10151-10153
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiated
Packaging Details: Pallets or Wooden Case
Delivery Time: 7-15 days after deposit
Payment Terms: L/C, T/T,Western Union
Supply Ability: 2000sets per month
Contact Now
Detailed Product Description
Sheave Material: MC Nylon Sheave Size: 916*800*110mm,916*800*125mm
Max Conductor: LGJ720 Rated Load: 50-150KN
Sheaves Numbers: 1-5 Usage: 916mm Large Diameter Bundle Stringing Blocks
Item: Stringing Pulley Blocks Application: Transmission Line
High Light:

MC Nylon Wire Rope Pulley Block

,

916mm Wire Rope Pulley Block

,

ACSR Conductor 916mm Pulley Block

916mm ACSR MC Nylon Conductor Wire Rope Stringing Pulley Blocks



Our 916mm Large Diameter Stringing Block has the maximum suitable conductor LGJ720. In detail, the aluminum

of this conducting wire can possess the largest cross section of up to 720 square millimeters.

The dimension of block (outside diameter*root diameter*sheave width) is Φ916× Φ 800× 110 (mm).



1. Maximum suitable conductor ACSR720.

2. Sheave dimension ( outside diameter× root diameter × sheave width) Φ916×Φ800×110(mm).

3. The middle sheave can be customized as cast steel sheave



916mm Main Specifications

Item Number Model Number of Sheave Rated Load (KN) Weight (kg) Sheave Feature
10151 SHDN916 1 50 51 MC nylon sheave
10152 SHSQN916 3 75 120
10153 SHWQN916 5 150 200

The middle sheave can be customized as cast steel sheave



916mm ACSR MC Nylon Conductor Wire Rope Stringing Pulley Blocks 0



916mm ACSR MC Nylon Conductor Wire Rope Stringing Pulley Blocks 1
