| Place of Origin: | Ningbo,China |
| Brand Name: | Suntech |
| Certification: | ISO |
| Model Number: | BHW1100CD |
| Minimum Order Quantity: | 100pcs |
|---|---|
| Price: | Get Latest Price |
| Packaging Details: | Inner boxes and outside cartons or customize packing |
| Delivery Time: | 25days after deposit |
| Payment Terms: | L/C, T/T, Western Union, D/P, D/A |
| Supply Ability: | 60000pcs/month |
| Capacity: | 1100kg/2500lbs | Power Source: | Hand Manual Source |
|---|---|---|---|
| Product Name: | Worm Gear Drum Hand Winch | Gear Ratio: | 31:1/41:1/51:1 |
| Gear Treatment: | Color Power Or Zinc Plated | Warranty: | One Year |
| Brake: | Hand Brake | Material: | Body / Steel A3 |
| High Light: | worm gear hand winch,worm gear boat winch,worm hand winch |
||
2500 lb Worm Gear Drum Winch , Heavy Duty Hand Winch For Lifting
Wire cable worm gear hand winch for crane pulling
Our Worm Gear Winch can be mainly used for horizontal towing. Which suits especially for farm as a swich to control Cage door; Also can be widely applied on industrial and agricultural application. We offer cable wire, and only winch version and more than 50 types; Work load:range from 1500lbs(700kg) to 3000lbs(1350kg).
Worm gear hand winch is easy-to-mount and ideal for mobile use on pickup trucks and trailers. The worm gear winch features steel towing cable and a smooth-action worm gear drive to keep a firm hold on items in tow.
Product Specifications,
| Model | BHW600CS | BHW600CD | BHW900CS | BHW900CD | BHW1100CS | BHW1100CD |
| Capacity (Lbs) | 400kg(880lbs) | 400kg(880lbs) | 900kg(2000lbs) | 900kg(2000lbs) | 1100kg(2500lbs) | 1100kg(2500lbs) |
| Gear ratio | 31:1 | 31:1 | 41:1 | 41:1 | 51:1 | 51:1 |
| Drum | Single | Divided | Single | Divided | Single | Divided |
| Drum-hub Diameter(mm) | ￠38 | ￠38 | ￠38 | ￠38 | ￠50 | ￠50 |
| Cable Diameter(mm) | ￠4.8 | ￠4.8 | ￠5.0 | ￠5.0 | ￠5.6 | ￠5.6 |
| Cable Length(m) | 8 | 15 | 15 | 15 | 30 | 30 |
| Hook Type | "Snap" hook | "Snap" hook | "Snap" hook | "Snap" hook | "Snap" hook | "Snap" hook |
| Surface Treatment | Black Spraying | Black Spraying | Black Spraying | Black Spraying | Black Spraying | Black Spraying |
| Hand length (mm) | 280 | 280 | 280 | 280 | 280 | 280 |
| N.W(kg)/pcs | 4.3 | 4.3 | 5.5 | 5.5 | 6.7 | 6.7 |
| Pcs/Each Carton | 4pcs | 4pcs | 4pcs | 4pcs | 4pcs | 4pcs |
