2600Lb Boat Stainless Steel Hand Winch With Brake

2600Lb Boat Stainless Steel Hand Winch With Brake

  • 2600Lb Boat Stainless Steel Hand Winch With Brake
2600Lb Boat Stainless Steel Hand Winch With Brake
Product Details:
Place of Origin: Ningbo,Zhejiang,China
Brand Name: Newart
Certification: ISO
Model Number: LDE2600N
Payment & Shipping Terms:
Minimum Order Quantity: 500pcs
Price: Get Latest Price
Packaging Details: Inner Box and outside carton
Delivery Time: 25-30days after payment
Payment Terms: L/C, T/T, Western Union
Supply Ability: 8000pcs/month
Contact Now
Detailed Product Description
Capacity: 2600LBS Power Source: Hand Source
Application: Lifting Material: Steel A3 Or Stainless Steel
Gear Ratio: 10:1 Brake System: Automatic Brake
Certification: CE Surface Treatment: Power Coated Or Zinc Plated
High Light:

stainless steel hand winch with brake


2600Lb Stainless Steel Hand Winch


2600Lb Boat Hand Winch

2600lbs Black Color Marine Hand Winch Automatic Brake With CE Approved


The automatic brake winch ensures the load remains suspended when the crank is released and avoids unchecked descent of the load;Newart provides the extra hands you need for fast and sure tow make-up and breakdown with a complete line of hand winches in both left and right hand models



Heavy gauge zinc plated steel frame.

Adapts for ratcheting or free spooling.

Five slots in base to allow multiple fixing positions to suit most trailers, boats, caravans.

Ratchet Type: Two Way, The higher position is for pulling, the lower position is for releasing, the middle position is for both pulling and releasing, but can only be used when unloaded.

Ideal use on pickup trucks, trailers and other mobile applications.

Installs easy with bolts and lock nuts (not included).


Product Name: Hand Brake Winch

Work Load: 2600lbs

Gear Ratio: 10:1


Model LDE1200C LDE1800C LDE2600C
Safe working load (Lbs) 1200 1800 2600
Test load (KN) 8 12.13 17.64
Drum-hub Diameter (mm) ¢48.5 ¢60 ¢80
Gear ratio 4.2:1 5:1 10:1
Hand length (mm) 210 320 320
N.W/G.W (kg) 3.7/4.5 8.1/9.0 10.4/11.5
Package size (cm) 16X16X22 35X20X23 35X24X24


About us: Suntech Power Tools, which located in the southeast China, it is the earliest origin Power Tools Leading City in China.We are making the various related cable pulling tools, and hydraulic tension and puller to support the transmission work.All canaccept OEM and professionally produced per ISO 9001:2008, they are being sold to over more than 50 countries in the world,and has wined the best brand reputations. Some items like the stringing blocks,cable rollers,the cable jack stands,etc we can customized, and the Construction Safety Tools ,are not demanded the MOQ. You can freely help you out either
