Manual Chain Hoist 5-200KN Rated Load with Manual Hand Chain Operation and Zinc-Plated Finish for Power Line Construction

1 Piece
MOQ
Get the latest price
Price
Manual Chain Hoist 5-200KN Rated Load with Manual Hand Chain Operation and Zinc-Plated Finish for Power Line Construction
Features Gallery Product Description Request A Quote
Features
Specifications
Name: Manual Chain Hoist
Model: 14282 / 14292 / 14302 / 14312 / 14321 / 14331 / 14341 / 14351
Rated Load: 5-200KN
Standard Lifting Height: 3m (4m / 5m / 6m / 8m / 10m Options)
Weight: 10-193kg
Weight Of 1m Chain: 1.7-19.4kg
Mechanism: Manual Hand Chain
Warranty: 1 Year
Highlight:

5-200KN Rated Load Manual Chain Hoist

,

Manual Hand Chain Operation Chain Block

,

Zinc-Plated Finish Hand Chain Hoist
Basic Infomation
Place of Origin: Ningbo, China
Brand Name: Suntech
Certification: ISO 9001
Model Number: Manual Chain Hoist
Payment & Shipping Terms
Packaging Details: Plywood case with steel-banded reinforcement for export
Delivery Time: 3-7 working days for stock, 15-25 days for bulk orders
Payment Terms: L/C,T/T
Supply Ability: 3000 Pieces per Month
Product Description
Manual Chain Hoist 5-200KN for Lifting and Positioning on Power Line Work
The manual chain hoist is a hand operated chain block for lifting, holding and positioning loads on power line and industrial work. Its hand chain drives alloy steel gears that raise and lower the load in controlled steps, while an automatic brake keeps it in place when the operator lets go. Eight models cover rated loads from 5KN to 200KN, with a standard 3m lifting height and chain length options up to 10m.
Design and Operation
  • Manual hand chain operation: precise, controlled load positioning.
  • High-grade alloy steel gears: built for repeated lifting under load.
  • Reinforced load chain: standard 3m lift, with 4m to 10m versions available.
  • Automatic brake system: holds the load when the hand chain is released.
  • Zinc-plated finish: corrosion protection for outdoor use.
  • Replaceable wear components: easier servicing in the field.
Technical Specifications
Item No.Rated Load (KN)Min. Hook Distance (mm)Lifting Chain LinesNet Weight (kg)Weight of 1m Chain (kg)
1428252801101.7
14292103201121.7
14302153901192.3
14312204101202.3
14321304852273.7
1433150600245.55.6
143411008204839.7
143512001040819319.4
Chain Length Options
Lifting Height5KN10KN15KN20KN30KN50KN100KN200KN
3m (standard)1428214292143021431214321143311434114351
4m1428314293143031431314322143321434214352
5m1428414294143041431414323143331434314353
6m1428514295143051431514324143341434414354
8m////14325143351434514355
10m////14326143361434614356
Quality Control and Testing
Gears, chain, hooks and frames are assembled and checked for chain feed, brake hold and general function before packing. Each batch is inspected against its stated rated load. Products are manufactured under ISO 9001 certified quality management, and an inspection record is supplied with every shipment.
Typical Applications
  • Transmission tower assembly
  • Substation equipment installation
  • Temporary cable support
  • Emergency repair operations
Handling and Care
  • Before use: inspect the chain and hooks, and verify the load rating.
  • In use: keep a steady lifting speed and watch the load position.
  • After use: clean off dirt, lubricate the chain and gears, and store in a dry place.
Factory Support and Buyer Assurance
  • Manufacturer-direct pricing with no trading-layer mark-up
  • OEM and ODM available with custom lifting heights, chain lengths and branding
  • Model selection support (5KN to 200KN) based on load and lift
  • Chain length options of 4m, 5m, 6m, 8m and 10m
  • 12-month limited warranty on the gear mechanism
Tell us your load and required lifting height, and our engineers will confirm the right model and a factory-direct quotation within one working day.
