Vertical Cable Reel Stand with 10-70KN Rated Load and Space-Saving Vertical Design for 500-1500mm Reels

1 Piece
MOQ
Get the latest price
Price
Vertical Cable Reel Stand with 10-70KN Rated Load and Space-Saving Vertical Design for 500-1500mm Reels
Features Gallery Product Description Request A Quote
Features
Specifications
Name: Vertical Type Cable Reel Stand
Model: SIW-1 / SIW-3A / SIW-3B / SIW-5A / SIW-7A
Item No.: 15131 / 15132 / 15133 / 15133A / 15135
Diameter Range: 500-1500mm
Rated Load: 10-70KN
Weight: 36-170kg
Design: Vertical Upright Storage
Warranty: 1 Year
Highlight:

10-70KN Rated Load Vertical Cable Reel Stand

,

Space-Saving Vertical Design Cable Reel Stand

,

500-1500mm Diameter Range Conductor Drum Stand
Basic Infomation
Place of Origin: China
Brand Name: Suntech
Certification: ISO 9001
Model Number: SIW-1
Payment & Shipping Terms
Packaging Details: Plywood case with steel-banded reinforcement for export
Delivery Time: 3-5 working days for stock, 15-25 days for bulk orders
Payment Terms: L/C,T/T
Supply Ability: 5000 Pieces per Month
Product Description
Vertical Cable Reel Stand for Space-Saving Storage and Smooth Cable Deployment
The Vertical Cable Reel Stand holds and pays out cable on edge rather than on a horizontal axle, so a reel that would occupy a wide bay on a cradle stands in a fraction of the floor area. Five models cover reel diameters from 500mm to 1500mm and rated loads from 10KN to 70KN, letting power plants, substations and cable stores keep more reels accessible within the same footprint.
Why Vertical Works on Site
  • Upright footprint: frees floor space in busy substations and cable stores where horizontal cradles are impractical.
  • Reinforced steel frame: support arms hold the reel steady while it rotates for deployment.
  • Cable protection: rounded contact surfaces and deburred edges protect cable jackets during payout.
  • Locking mechanism and stable base: prevent accidental rotation and tipping on uneven floors.
  • Quick reel loading: smaller models can be mounted and swapped without a crane.
  • Easy rotation: a single operator can turn the reel for controlled, orderly deployment.
Technical Specifications
Item No.ModelReel Diameter (mm)Rated Load (KN)Weight (kg)
15131SIW-15001036
15132SIW-3A8003044
15133SIW-3B10003055
15133ASIW-5A120050100
15135SIW-7A150070170
Quality Control and Testing
Frames are fabricated from steel tube and plate, welded under a documented procedure, checked for squareness on a jig, and coated against corrosion before packing. Every surface that touches the cable is deburred and smoothed, and each stand is inspected before shipment. Production runs under ISO 9001 certified quality management.
Typical Applications
  • Power plant cable management
  • Substation wiring projects
  • Temporary power installations
  • Cable storage yards and warehouses
Factory Support and Buyer Assurance
  • Manufacturer-direct pricing with no trading-layer mark-up
  • OEM and ODM available with custom sizes, colours and branding
  • Model selection support (SIW-1 to SIW-7A) based on reel diameter and load
  • Spare support arms, bearings and locking parts held in stock
  • 12-month limited warranty
Tell us your reel diameter and required load, and our engineers will recommend the right SIW model and confirm a factory-direct quotation within one working day.
