Home /Products/Tower Erection Tools/6.3-9KW Double Drum Winch for Power Line Construction JJCS-50J

6.3-9KW Double Drum Winch for Power Line Construction JJCS-50J

1 PCS
MOQ
Negotiation
Price
6.3-9KW Double Drum Winch for Power Line Construction JJCS-50J
Features Gallery Product Description Request A Quote
Features
Specifications
Name: Double Drum Winch
Item No.: 09151-09162
Model: JJCS-50J
Power: 6.3-9KW
Speed: 2000-3600RPM
Weight: 270-700KG
Highlight:

Aluminum Overhead Line Conductor

,

1033.5 Bluebell MCM Cable

,

AAC All Aluminum Conductor
Basic Infomation
Place of Origin: Ningbo,China
Brand Name: Suntech
Certification: ISO9001,CCC
Model Number: JJCS-50J
Payment & Shipping Terms
Packaging Details: Plywood Case
Delivery Time: 3-5days
Payment Terms: L/C,T/T
Supply Ability: 8000 PCS/month
Product Description
Professional Double Drum Winch For Power Line Construction
Attribute Value
Name Double Drum Winch
Item No. 09151-09162
Model JJCS-50J
Power 6.3-9KW
Speed 2000-3600RPM
Weight 270-700KG
Product Introduction
  • Essential dual-cable handling equipment for power line projects
  • Designed for simultaneous or independent cable operations
  • Trusted by utility professionals for reliability and versatility
Key Features
Dual Drum Operation
  • Independent drum control system
  • Simultaneous or separate cable handling
Robust Construction
  • Steel drums with reinforced flanges
  • Heavy-duty frame and mounting system
Safety Assurance
  • Independent braking for each drum
  • Load limit protection devices
Operational Efficiency
  • Smooth cable feeding and guiding
  • Precise tension control
Maintenance Advantages
  • Self-lubricating bearing systems
  • Easy access for service and maintenance
Typical Applications
  • Parallel cable installation
  • Guy wire tensioning operations
  • Substation cable pulling
  • Emergency restoration work
Workflow Integration
  • Compatible with standard pulling grips
  • Works with all common cable types
  • Integrates with tension monitoring systems
Maintenance Benefits
  • Corrosion-resistant components
  • Minimal maintenance requirements
  • Long service life
User Guidelines
Setup
  • Secure winch to stable foundation
  • Check cable alignment on both drums
Operation
  • Maintain controlled pulling speeds
  • Monitor both drum tensions
Post-Use
  • Clean and inspect all components
  • Store in dry protected area
Industry Compliance
  • Meets OSHA equipment standards
  • Complies with IEEE specifications
  • Certified by major utilities
Why Professionals Choose Us
  • 35% more efficient than single drum systems
  • 40% more versatile operation capabilities
  • 1-year performance warranty
Customer Support
  • Free operation training
  • 24/7 technical support
  • Replacement parts program
Purchasing Options
  • Single units or complete systems
  • Custom configurations available
  • Volume discounts for utilities
Technical Specifications
Item No. 09151 09152 09162
Model JJCS-50J JJQS-50J JJCS-50T
Engine KF186A Diesel Engine Honda 390 Gasoline Engine S195G Diesel Engine
Power(KW) 6.3 6.6 9
Speed(RPM) 2600 3600 2000
Pull force (KN)/ Speed (M/MIN) Slow 50*6.0,30/10 50/6.0,30/10 50/3.1,40/9.6
Moderate / / 45/7.1,17/22.3
Fast 13/23,10/30 13/23,10/30 33/11.3,10/35.6
Reverse -/5,-/17 -/5,-/17 -/7.35
Drum bottom of groove diameter Φ230 Φ230 Φ300
Outline size(MM) 1280*770*600 1280*770*600 2440*1300*1140
Weight(KG) 280 270 700
6.3-9KW Double Drum Winch for Power Line Construction JJCS-50J 0
