ACAR Overhead Transmission Bare Aluminum Conductor Alloy Reinforced

Product Details:

Place of Origin:	Ningbo,China
Brand Name:	Suntech
Certification:	ISO9001,CCC
Model Number:	ACAR

Payment & Shipping Terms:

Minimum Order Quantity:	1000m
Price:	Negotiation
Packaging Details:	Exported Wooden Case or Containers
Delivery Time:	5-7 workdays
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	6000Ton/Month

Contact Now

Detailed Product Description

Name:	All Aluminum Conductor Alloy Reinforced	Jacket:	Non-sheathing Bare
Application:	Power Transmission	Conductor Type:	Solid
Standard:	State Grid,Power Station	Material:	Aluminum
High Light:	Bare All Aluminium Alloy Conductor , Overhead Transmission Aluminium Bare Conductor , Alloy Reinforced Bare Overhead Conductors

ACAR Overhead Transmission All Aluminum Conductor Alloy Reinforced

1.Application:
Bare conductor (ACSR, ACCC, AAAC, AAC, etc) has been widely used in power transmission lines and electricity distribution lines
with various voltage levels, because they have such good characteristics as simple structure, convenient installation and
maintenance, low cost large transmission capacity. And they are also suitable for laying across rivers valleys and the places
where special geographical features exist.

2.Features:
a. high tensile strength
b. better sag properties
c. economic design
d. best suited for transmission lines with long spans

3. Working Conditions:
Ambient temperature: Above -20 °C
Working temperature: Not exceed 80 °C
Laying bending radius: Not less than 30 times the cables outer diameter

4. Standards:
We can produce as per the standard of GB, IEC, ASTM,DIN,CSA,JIS and also particularly customize and manufacture according to your
special requirement.

Product details

Standards	IEC 61089 / ASTM B 231/B 231M / DIN 48201-5
Cross section	6awg,4awg,2awg,1awg,1/0awg,2/0awg,3/0awg,4/0awg,250mcm---3500mcm.
Construction	Conductor: Aluminum 1350-H-19 wires
Production Scope:	Max. size 2000mm2( 4000MCM)/ Max. str. no. 127 wires
Name	all aluminium conductor (AAC)
Application:	Overhead transmission and primary and secondary distribution.
Packaging	Standard seaworthy drum (wooded rum,wooded steel drum, steel drum)
Product Keywords	hard drawn aluminum conductor,all aluminium conductors,overhead transmission line conductor

AAC overhead conductor DIN 48201

Code Number	Calculated Area	Stranding and Wire Diameter	Overall	Linear	Calculated	Max. D.C.
Code Number	Calculated Area	Stranding and Wire Diameter	Diameter	Mass	Breaking load	Resistance at 20°C
mm2	mm2	mm	mm	Kg/km	daN	Ω/km
16	15.89	7/1.70	5.1	44	290	1.8018
25	24.25	7/2.10	6.3	67	425	1.1808
35	34.36	7/2.50	7.5	94	585	1.8332
50	49.48	7/3.00	9	135	810	0.5786
50	48.36	19/1.80	9	133	860	0.595
70	65.82	19/2.10	10.5	181	1150	0.4371
95	95.27	15/2.50	12.5	256	1595	0.3084
120	117	19/2.80	14	322	1910	0.2459
150	147.1	37/2.25	15.2	406	2570	0.196
185	181.6	37/2.50	17.5	501	3105	0.1587
240	242.54	61/2.25	20.2	670	4015	0.1191
300	299.43	61/2.50	22.5	827	4850	0.0965
400	400.14	61/2.89	26	1105	6190	0.07221
500	499.83	61/3.23	29.1	1381	7600	0.05781
625	626.2	91/2.96	32.6	1733	9690	0.04625
800	802.1	91/3.35	36.8	2219	12055	0.03611
1000	999.71	91/3.74	41.1	2766	14845	0.02897
