Vertical Type Cable Reel Stand Heavy Duty Steel Frame For High Voltage Cable Projects​

Vertical Type Cable Reel Stand Heavy Duty Steel Frame For High Voltage Cable Projects​

​​1. PRODUCT OVERVIEW​​

The Vertical Type Cable Reel Stand is engineered for power transmission and distribution projects requiring efficient cable management in confined spaces. Its vertical orientation minimizes footprint while maintaining robust load-bearing capacity. The stand features a welded steel frame construction with reinforced joints, specifically designed to handle heavy cable drums up to 1.5m in diameter. Unlike traditional horizontal stands, this model optimizes workspace efficiency, making it ideal for urban underground cable laying, tunnel installations, and indoor substation work.

​​2. STRUCTURAL DESIGN​​

• ​​Frame Material​​: 5mm thick Q235B carbon steel with hot-dip galvanized coating
• ​​Base Dimensions​​: 800mm x 800mm square configuration with 4 adjustable leveling feet
• ​​Height Adjustment​​: 6-position pin-lock system (1.0m/1.2m/1.4m/1.5m/1.6m/1.8m)
• ​​Load Capacity​​: 500kg working load (750kg ultimate safety limit)
• ​​Rotation Mechanism​​: 360° smooth rotation with sealed ball bearings

​​3. OPERATIONAL FEATURES​​

• ​​Anti-Tilt Stability​​: The weighted base prevents tipping during high-tension cable pulls
• ​​Drum Locking​​: Spring-loaded locking pins secure cable reels during transport
• ​​Brake System​​: Manual friction brake controls cable unwinding speed (3 adjustable levels)
• ​​Modular Assembly​​: Base, column, and top assembly disconnect for compact storage

​​

4. PERFORMANCE ADVANTAGES​​

• ​​Space Efficiency​​: Occupies 60% less floor space than horizontal stands
• ​​Labor Savings​​: Single operator can handle drum changes in under 2 minutes
• ​​Durability​​: Galvanized coating withstands 1000+ hours in salt spray testing
• ​​Safety Compliance​​: Meets IEC 61439-1 standards for electrical construction equipment

​​

5. TYPICAL APPLICATIONS​​

• ​​Urban Power Grids​​: Underground cable laying in congested city areas
• ​​Renewable Energy​​: Wind farm collector systems and solar park interconnections
• ​​Industrial Plants​​: High-voltage cable installations in manufacturing facilities
• ​​Transportation​​: Railway tunnel electrification and subway power systems

​​

6. MAINTENANCE PROTOCOL​​

• ​​Daily​​: Visual inspection for structural damage or loose components
• ​​Weekly​​: Lubricate rotation mechanism with lithium-based grease
• ​​Monthly​​: Verify all bolt torques to 50Nm specification
• ​​Annually​​: Reapply anti-corrosion coating if surface scratches exceed 5% area

​​7. ECONOMIC BENEFITS​​

• ​​ROI Calculation​​: Replaces 2 laborers typically required for manual handling (payback in 5 months)
• ​​Cable Protection​​: Prevents $12,000+ in potential damage per drum from improper handling
• ​​Logistics Savings​​: 8 stands fit in same truck space previously needed for 3 horizontal units
• ​​Longevity​​: 10-year structural warranty with proper maintenance

​​8. COMPARATIVE ADVANTAGES​​

Compared to conventional horizontal cable stands:

• ​​30% faster​​ cable deployment in confined spaces
• ​​50% reduction​​ in worksite accidents related to drum handling
• ​​40% lower​​ lifetime maintenance costs due to galvanized protection
