Name: MVNO Tapered Tubular Monopole Telecommunications Tower
Brand: Ningbo Suntech Power Machinery Tools Co.,Ltd.
SKU: Monopole Tower
Price: 285,715.00 USD
Availability: InStock

Features Gallery Product Description Request A Quote

Features

Specifications

Material Grade: Tube Steel ASTM A36 A572 Gr50/S275JR S275JR.

Height: 10-80m

Wind Speed: 40M/S

Type: Telecommunication Tower

Model Number: 3 Legs Tube Tower

Name: 45 Meter Angle Steel Lattice Self Supporting Communication Tower

Highlight:

Tubular Monopole Telecommunications Tower

Tapered Monopole Telecommunications Tower

MVNO Monopole Telecom Tower

Basic Infomation

Place of Origin: China

Brand Name: Suntech

Certification: ISO

Model Number: Monopole Tower

Payment & Shipping Terms

Packaging Details: Exported Containers

Delivery Time: 35-45days after deposit

Payment Terms: L/C, T/T, Western Union

Supply Ability: 60000 Metric Ton/Metric Tons Per Year

Gallery

MVNO Tapered Tubular Monopole Telecommunications Tower

Product Description

Mvno Tapered Tubular Telecom Tower Cell Gsm Telecommunication Monopole Tower

Quick Detail:

Self-Supporting Towers are appropriate for nearly all wireless communication applications. Self-Supporting Towers

are typically three or four sided lattice type structures made from solid rod, pipe, or angle. Self-supporting Towers

are ideal for installations where space requirements are limited.

Technical Data

Design
1. Design Code	TIA/EIA-222-G/F
Structure Steel
2. Grade	Mild Steel	High Tensile Steel
	GB/T 700:Q235B, Q235C,Q235D	GB/T1591:Q345B, Q345C,Q3455D
	ASTM A36	ASTM A572 Gr50
	EN10025: S235JR, S235J0,S235J2	EN10025: S355JR, S355J0,S355J2
3. Design Wind Speed	Up to 250 km/h
4. Allowable deflection	0.5 ~1.0 degree @ operational speed
5. Tension strength (Mpa)	360~510	470~630
6. Yield strength (t≤16mm) (Mpa)	355	235
7. Elongation (%)	20	24
8. Impact strength KV (J)	27(20°C)---Q235B(S235JR)	27(20°C)---Q345B(S355JR)
	27(0°C)---Q235C(S235J0)	27(0°C)---Q345C(S355J0)
	27(-20°C)---Q235D(S235J2)	27(-20°C)---Q345D(S355J2)
Bolts & Nuts
9. Grade	Grade 4.8, 6.8, 8.8
10. Standards for mechanical properties
10.1 Bolts	ISO 898-1
10.2 Nuts	ISO 898-2
10.3 Washers	ISO 6507-1
11. Standards for Dimensions
11.1 Bolts	DIN7990, DIN931, DIN933
11.2 Nuts	ISO4032, ISO4034
11.3 Washers	DIN7989, DIN127B, ISO7091
Welding
12. Method	CO2 Shielded Arc Welding & Submerged Arc Welding(SAW)
13. Standard	AWS D1.1
Marking
14. Method of marking of the members	Hydraulic Press Stamping
Galvanizing
15. Galvanization standard of steel sections	ISO 1461 or ASTM A123
16. Galvanization standard of bolts and nuts	ISO 1461 or ASTM A153
Test
17. Factory test	Tensile test,Elements analysis, Sharpy test(impact test), Cold Bending, Preece test,Hammer test

Production Process And Quality Control

Main Features
1. We can supply the product base on client required drawing ,but also can supply the design for any kinds

of lamp poles ,electric poles ,street lighting poles, high mast poles ,garden light poles , outdoor lighting

,outdoor lighting poles ,flag poles ,traffic light poles ,lighting ,road lighting pole.
2. Material :hot rolled coil from Q235 to Q460 ,ASTM573 GR65, GR50 ,SS400, SS490,ST52-3 equivalent

standard materials
3. deal: Hot dip galvanized Following ASTM A 123 or any other standard by client required.
4. Packing: Plastic bulble , Mat &Straw Bale or following client required
5. Length : within 16meters once forming( single section)
6. Thickness: from 1mm to 25mm
7. Shape: polygonal(6-side,8side,12-side,16side) round tapered.
8. 110KV to 220kv
9. Easy install and maintenance.
