MVNO Tapered Tubular Monopole Telecommunications Tower

MVNO Tapered Tubular Monopole Telecommunications Tower

  • MVNO Tapered Tubular Monopole Telecommunications Tower
  • MVNO Tapered Tubular Monopole Telecommunications Tower
MVNO Tapered Tubular Monopole Telecommunications Tower
Product Details:
Place of Origin: China
Brand Name: Suntech
Certification: ISO
Model Number: Monopole Tower
Payment & Shipping Terms:
Minimum Order Quantity: 1 Tower
Price: Get the latest prices
Packaging Details: Exported Containers
Delivery Time: 35-45days after deposit
Payment Terms: L/C, T/T, Western Union
Supply Ability: 60000 Metric Ton/Metric Tons Per Year
Contact Now
Detailed Product Description
Material Grade: Tube Steel ASTM A36 A572 Gr50/S275JR S275JR. Height: 10-80m
Wind Speed: 40M/S Type: Telecommunication Tower
Model Number: 3 Legs Tube Tower Name: 45 Meter Angle Steel Lattice Self Supporting Communication Tower
High Light:

Tubular Monopole Telecommunications Tower

,

Tapered Monopole Telecommunications Tower

,

MVNO Monopole Telecom Tower

Mvno Tapered Tubular Telecom Tower Cell Gsm Telecommunication Monopole Tower



Quick Detail:

Self-Supporting Towers are appropriate for nearly all wireless communication applications. Self-Supporting Towers

are typically three or four sided lattice type structures made from solid rod, pipe, or angle. Self-supporting Towers

are ideal for installations where space requirements are limited.



Technical Data

Design
1. Design Code TIA/EIA-222-G/F
Structure Steel
2. Grade Mild Steel High Tensile Steel
GB/T 700:Q235B, Q235C,Q235D GB/T1591:Q345B, Q345C,Q3455D
ASTM A36 ASTM A572 Gr50
EN10025: S235JR, S235J0,S235J2 EN10025: S355JR, S355J0,S355J2
3. Design Wind Speed Up to 250 km/h
4. Allowable deflection 0.5 ~1.0 degree @ operational speed
5. Tension strength (Mpa) 360~510 470~630
6. Yield strength (t≤16mm) (Mpa) 355 235
7. Elongation (%) 20 24
8. Impact strength KV (J) 27(20°C)---Q235B(S235JR) 27(20°C)---Q345B(S355JR)
27(0°C)---Q235C(S235J0) 27(0°C)---Q345C(S355J0)
27(-20°C)---Q235D(S235J2) 27(-20°C)---Q345D(S355J2)
Bolts & Nuts
9. Grade Grade 4.8, 6.8, 8.8
10. Standards for mechanical properties
10.1 Bolts ISO 898-1
10.2 Nuts ISO 898-2
10.3 Washers ISO 6507-1
11. Standards for Dimensions
11.1 Bolts DIN7990, DIN931, DIN933
11.2 Nuts ISO4032, ISO4034
11.3 Washers DIN7989, DIN127B, ISO7091
Welding
12. Method CO2 Shielded Arc Welding & Submerged Arc Welding(SAW)
13. Standard AWS D1.1
Marking
14. Method of marking of the members Hydraulic Press Stamping
Galvanizing
15. Galvanization standard of steel sections ISO 1461 or ASTM A123
16. Galvanization standard of bolts and nuts ISO 1461 or ASTM A153
Test
17. Factory test Tensile test,Elements analysis, Sharpy test(impact test), Cold Bending,
Preece test,Hammer test



Production Process And Quality Control

MVNO Tapered Tubular Monopole Telecommunications Tower 0

Main Features
1. We can supply the product base on client required drawing ,but also can supply the design for any kinds
of lamp poles ,electric poles ,street lighting poles, high mast poles ,garden light poles , outdoor lighting
,outdoor lighting poles ,flag poles ,traffic light poles ,lighting ,road lighting pole.
2. Material :hot rolled coil from Q235 to Q460 ,ASTM573 GR65, GR50 ,SS400, SS490,ST52-3 equivalent
standard materials
3. deal: Hot dip galvanized Following ASTM A 123 or any other standard by client required.
4. Packing: Plastic bulble , Mat &Straw Bale or following client required
5. Length : within 16meters once forming( single section)
6. Thickness: from 1mm to 25mm
7. Shape: polygonal(6-side,8side,12-side,16side) round tapered.
8. 110KV to 220kv
9. Easy install and maintenance.

MVNO Tapered Tubular Monopole Telecommunications Tower 1
