Place of Origin: | China |
Brand Name: | Suntech Tower |
Certification: | ISO, CE |
Model Number: | Tower-Landscape Lighthouse |
Minimum Order Quantity: | 1 Tower |
---|---|
Price: | Get the newest price |
Packaging Details: | Exported Containers |
Delivery Time: | 30-35 days after deposit |
Payment Terms: | L/C, T/T, Western Union |
Supply Ability: | 100000 Metric Ton/Metric Tons Per Year |
Product Name: | Tower-Landscape Lighthouse | Material List: | Steel Q345 Q245 Q420 |
---|---|---|---|
Height: | 10-120m | Surface Treatment: | Hot Dip Galvanized |
Wind Speed: | 110~180km/h 3 Second Gust | Application: | Monopole Tower |
High Light: | Telecommunication Steel Tower Q345,Q235B Carbon Telecommunication Steel Tower,Lighthouse Monopole Tower |
Telecommunication Steel Pole Tower-Landscape Lighthouse
Telecommunication Pole Tower-Landscape Lighthouse Monopole Tower
Suntech Power Group is one of the largest Procurement, Engineering & Contracting Group companies in China.Our group branch company and factory have already engaged in field of electric power more than 26 years
Monopole advantages:
Small tower footprint and foundation
Fast and easy to erect
Aesthetically pleasing
Versatile for different loading applications
With tapered monopoles becoming more popular in the wireless industry, NELLO invested in a plant that is capable
of producing thousands of poles a year. Some NELLO monopole advantages are listed below:
3. Technical Data
Design | ||
1. Design Code | TIA/EIA-222-G/F | |
Structure Steel | ||
2. Grade | Mild Steel | High Tensile Steel |
GB/T 700:Q235B, Q235C,Q235D | GB/T1591:Q345B, Q345C,Q3455D | |
ASTM A36 | ASTM A572 Gr50 | |
EN10025: S235JR, S235J0,S235J2 | EN10025: S355JR, S355J0,S355J2 | |
3. Design Wind Speed | Up to 250 km/h | |
4. Allowable deflection | 0.5 ~1.0 degree @ operational speed | |
5. Tension strength (Mpa) | 360~510 | 470~630 |
6. Yield strength (t≤16mm) (Mpa) | 355 | 235 |
7. Elongation (%) | 20 | 24 |
8. Impact strength KV (J) | 27(20°C)---Q235B(S235JR) | 27(20°C)---Q345B(S355JR) |
27(0°C)---Q235C(S235J0) | 27(0°C)---Q345C(S355J0) | |
27(-20°C)---Q235D(S235J2) | 27(-20°C)---Q345D(S355J2) | |
Bolts & Nuts | ||
9. Grade | Grade 4.8, 6.8, 8.8 | |
10. Standards for mechanical properties | ||
10.1 Bolts | ISO 898-1 | |
10.2 Nuts | ISO 898-2 | |
10.3 Washers | ISO 6507-1 | |
11. Standards for Dimensions | ||
11.1 Bolts | DIN7990, DIN931, DIN933 | |
11.2 Nuts | ISO4032, ISO4034 | |
11.3 Washers | DIN7989, DIN127B, ISO7091 | |
Welding | ||
12. Method | CO2 Shielded Arc Welding & Submerged Arc Welding(SAW) | |
13. Standard | AWS D1.1 | |
Marking | ||
14. Method of marking of the members | Hydraulic Press Stamping | |
Galvanizing | ||
15. Galvanization standard of steel sections | ISO 1461 or ASTM A123 | |
16. Galvanization standard of bolts and nuts | ISO 1461 or ASTM A153 | |
Test | ||
17. Factory test | Tensile test,Elements analysis, Sharpy test(impact test), Cold Bending, Preece test,Hammer test |
|
Capacity | ||
18. Maximum Production Capacity | 50,000 TON per annum |
