​​Optical Cable Wire Gripper Heavy Duty Clamping Tool For Fiber Optic Cable Installation​

​​Optical Cable Wire Gripper Heavy Duty Clamping Tool For Fiber Optic Cable Installation​

Core Design Features​​

• ​​Non-marring jaw inserts​​ (UHMWPE or nylon) to protect delicate fiber optic cables
• ​​Manual screw-adjustable clamping force​​ for precise tension control (5-50kN WLL)
• ​​Lightweight aluminum alloy body​​ (6061-T6) with corrosion-resistant coating
• ​​Self-centering mechanism​​ ensures even pressure distribution on cables
• ​​Working Load Limit (WLL):​​ 3-30kN (color-coded for easy identification)
• ​​Compatible with 8-24mm diameter optical cables​​ (including ADSS/OPGW types)

​​Operational Advantages​​
✔ ​​Zero cable deformation​​ due to optimized pressure distribution
✔ ​​Tool-free jaw adjustment​​ with ergonomic handwheel
✔ ​​Corrosion-resistant​​ (ISO 9227 C4 class for coastal areas)
✔ ​​Integrated cable alignment guides​​ prevent twisting
✔ ​​Quick-release mechanism​​ for rapid cable insertion/removal

​​Safety Certifications​​
✓ ​​IEC 60794-1​​ optical cable handling compliance
✓ ​​IEEE 1138​​ OPGW installation standard
✓ ​​Non-conductive materials​​ (20kV dielectric strength)

​​Maintenance Specifications​​
• ​​Self-cleaning jaw grooves​​ require no lubrication
• ​​Field-replaceable wear pads​​ (tool-free change in <1 minute)
• ​​5000-cycle​​ service life guarantee
• ​​UV-resistant composite components​

​

​​Typical Applications​​
➔ ​​OPGW initial stringing operations​​
➔ ​​ADSS cable mid-span repairs​​
➔ ​​Fiber optic splice tension holding​​
➔ ​​Underground cable pulling guidance​​
➔ ​​Temporary bypass circuit setup​

​

​​Optional Accessories​​

• ​​Insulated hot-stick adapter​​ (for live work)
• ​​Laser alignment guide​​ for precise positioning
