Palm Tree Steel Monopole Tower Disguized Hot Dip Galvanized

Product Details:

Place of Origin:	China
Brand Name:	Suntech Tower
Certification:	ISO, CE
Model Number:	Steel Monopole Tower

Payment & Shipping Terms:

Minimum Order Quantity:	1 Tower
Price:	Get the Newest Price
Packaging Details:	Exported Containers
Delivery Time:	30-35 days after deposit
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	70000 Metric Ton/Metric Tons Per Year

Contact Now

Detailed Product Description

Name:	Steel Monopole Tower Disguized	Material:	Q235B & Q355B Equivalent To A36/S235JR & Gr50/S355JR
Height:	10-120m	Surface Treatment:	Hot-dip Galvanized And Specific Bark With Branches
Wind Speed:	110~180km/h_3 Second Gust	Lifetime:	20-30 Years
High Light:	Q235B Steel Palm Tree Tower , Q235B Steel Monopole Tower , Steel Monopole Tower Disguized

Communication Palm Tree Steel Monopole Tower Disguized With Hot Dip Galvanized

Suntech Power Group is one of the largest Procurement, Engineering & Contracting Group companies in China.Our group branch company and factory have already engaged

in the field of electric power more than 26 years.

Welcome to visit our website. Ningbo Suntech Power Machinery Co.,Ltd. is one of the largest professional manufacturers of transmission line tower in East of China. The company provides various galvanized steel structures, Stringing tools and equipments specialized in 500kV and below the line of power tower, substation structure, communication tower, electrified railway structure,stringing blocks,come clong clamp,gin pole,cable rolles,hydraulic puller tensioner,etc.

Monopole tower

Single tube tower also called monopole tower, is a commonly used type, with beautiful appearance,

covering an small area of 9 to 18 square meter, cost - effective , and is adopted by majority of the

construction. Tower body adopt more reasonable section, which is connected through high strength

bolt. It has the characteristics of easy installation and can adapt to a variety of complicated field site.

Guyed Tower

Guyed tower has a novel appearance,and its biggest characteristic is strengthened by using steel guy wire.

Guyed tower is a common type of communication tower which is economical and practical. It is lighter and

cheaper than the others. It is very suitable for the geographical wide areas.

Self Supporting Tower

Self supporting tower usually is 3leg of 4leg tower, and its material is steel pipe or angle steel. As for the

connection, tubular tower is connected by flange, and angle steel tower is connected by nuts and bolts.
Features:
1. Small coefficient of wind load, strong wind resistance.
2. Save land resource, convenient location.
3. Convenient transportation and installation.

Palm Tree Steel Monopole Tower Disguized Hot Dip Galvanized 0

Production Process

Here is fabrication process for our transmission tower; however, both parties must discuss all drawings and confirm all shop drawings, technical specification, and which standard to conform. Before mass production, we must received all signed approved shop drawings and technical documents from our client.

Monopole cell tower telecom toweris a type of signal transmission tower, also called a signal transmission tower or a signal tower. Its main function is to support signal transmission and to support signal transmission antennas.
There are the following communication towers: angle steel four-post communication tower, steel pipe three-post communication tower, single-pole communication tower (beautified, bionic tree, light pole), lifting communication tower, and movable communication tower.

Telecommunication Tower- Goods description and major parameters
No.	Description	Detailed Specification and Major design Parameters
1	Design Code	ANSI/TIA222G, European Standard and others
2	Design Loading	1. Antenna load area as per specified by Clients worldwide.
		2. Wind speed as per requested by the clients.
		3. Deflection & Twist Angle, Exposure category, Topographic category as per specified by clients.
4	Structure Classification	II
5	Hot-dip galvanization	ISO 1461 2009, ASTM A123
6	Steel Grade	1. High strength low alloy structural steel: Q420B which is equivalent with ASTM Gr60
		2. High strength low alloy structural steels: Q345B which is equivalent with ASTM Gr50 or S355JR
		3. Carbon Structural Steel: Q235B which is equivalent with ASTM A36 or S235JR
7	Bolts and Nuts	Mainly ISO 898 grade 6.8 and 8.8 bolts
8	Foundation	50KPa, 100KPa, 150KPa soil bearing capacity mainly.
9	Tower Type	1. 3 Leg Self supported Angular Towers
		2. 3 Leg Self supported Tubular Towers
		3. 4 Leg Self supported Angular Towers
		4. 4 Leg Self supported Tubular Towers
		5. Guyed Mast
		6. Monopole Tower
		7. Camouflaged Tower: Palm Tree, Pine Tree, Coconut and others tree
		8. RDS Tower: Rapid Deploy Site/Tower
		9. Rooftop Towers
		10. Smart Poles
10	Warranty	1. Tower structures: 10 years
		2. Camouflaged towers
		a. Barks: 10 years
		b. Branches and leaves: 3 years
11	Return Period	50 Years
12	Accessories	1. Paint kits (ICAO standards): Water Based Acrylic Anticorrosive Paint which include Primer, International Orange/Red and Ivory White
		2. Aviation Light: 48V/220V Double Light and Single Light & Solar Light
		3. Lightning System: Lightning rod with 70mm2 G/Y copper cable down conductor or 25x3mm copper flat tape with clamps, and copper coated steel busbars or as per specified by clients.
		4. Earthing System: Earthing Rod with copper clad steel strand cable and lugs etc. or as per specified by Clients.
		5. ACDB as per specified by clients
		6. Fencing: Palisade fence and wire mesh fence with razor wires and gate.
		7. Fall arrest system: GB and CE certificate fall arrest system.
		8. Optical Fiber Cable: as per specified by client
		9. Generator: as per specified by client
		10. Canopy and Generator Cage: as per specified by clients
