Wear Resistant 10 - 750KV Monopole Telecom Tower ASTM Approved

Wear Resistant 10 - 750KV Monopole Telecom Tower ASTM Approved

  • Wear Resistant 10 - 750KV Monopole Telecom Tower ASTM Approved
  • Wear Resistant 10 - 750KV Monopole Telecom Tower ASTM Approved
Wear Resistant 10 - 750KV Monopole Telecom Tower ASTM Approved
Product Details:
Place of Origin: China
Brand Name: Suntech
Certification: ASTM Approved,ISO
Model Number: Monopole Cell Tower
Payment & Shipping Terms:
Minimum Order Quantity: 1 Tower
Price: Negotiation
Packaging Details: Exported Containers
Delivery Time: 30-35 days after deposit
Payment Terms: L/C, T/T
Supply Ability: 20000 Metric Ton/Metric Tons Per Year
Contact Now
Detailed Product Description
Material: Q235B & Q355B Equivalent To A36/S235JR & Gr50/S355JR Surface Treatment: Hot Dip Galvanization
Votage Grade: 10-750KV Application: Telecommunication Tower
Usage: Transmission Tower Wind Speed: 120KM/H
High Light:

750KV Monopole Telecom Tower

,

10KV Monopole Telecom Tower

,

Wear Resistant Monopole Cell Tower

Wear Resistant Telecom Tower Monopole Cell Tower 10 - 750KV ASTM Approved



Monopole cell tower telecom toweris a type of signal transmission tower, also called a signal transmission tower or a signal tower. Its main function is to support signal transmission and to support signal transmission antennas.
There are the following communication towers: angle steel four-post communication tower, steel pipe three-post communication tower, single-pole communication tower (beautified, bionic tree, light pole), lifting communication tower, and movable communication tower.



Detailed Product description as follows :

1. Circle /Polygonal

2. Slip joint/Flange Joint

3. Hot Dip Galvanization (ASTM123)

4. ISO9001 / ISO14001 certificate

5. Slip joints result in easy field assembly and erection

6. Painting Optional: according to customer's requirements

7. Design standard: TIA/EIA-222-G/F

8. Design software: MS TOWER



Products Features:

Available Height:10m-60M

Wind Pressure:50KM/H-280 KM/H

Material:main shaft :Q345B/S355JR/ASTM572;Spare parts:Q235B/S235JR/ASTM A36

Anchor bolts:grade 8.8 hot-dipped zinc galvanization

Zinc thickness: minimum 100um for main structure

Vivid appearance,less space,easy to install

Structure:Slip joint/Flange Joint

Lifetime:main shaft and steel parts more than 30 years

Delivery Lead Time: 35 Days after we receive deposit or LC

Antenna Loading Quantity Range:3-18 PCS

Microwave Dish loading Quantity Range :3-18 PCS

Working &Resting Platform Quantity Range:1-3 PCS

Concealed mounts available

Cable and Ladder: can be assembled by customer's request

Typically assembled and erected within a matter of hours

May be fitted with various combinations of feedline entry, feedline exit, and personal access ports

Cable line:supported on internal J-hooks

Earthing Cable and earthing bar : according to customer's request,generally our offer not including this part

Complete line of antenna mounts and accessories available

Provided with step bolts and cable-type safety climb system

Normal camouflaged pine tree tower including : lightning rod ,antenna support ,microwave suppport ,platform ,main section shaft,connection bolts ,anchor bolts ,templates ,internal/external ladder ,cable tray and etc

Aviation light: we can make it if customer request



Our Services

Our services include preliminary layouts, writing of contract specifications, bid solicitations, review of bid packages, final designs, inspections, project

management, and professional engineering certification. In addition to the fabrication of monopoles, self-supporting and guyed towers, we also can provide

fabrication and installation details. We provide structural analyses of telecom structures in accordance with applicable codes (Electronic Industries

Association,China Standard, American National Standards Institute, Uniform Building Code, and others).



Products 4G Cell Monopole Tower for Telecommunication Industry
Height 15-60m
Applications Telecommunication, Broadcasting, etc
Shape Conical, Round, Polygonal (Octagonal, Dodecagonal, Hexadecagonal, etc)
Material Hot Roll Steel Q235, Q345, Q420, Q460, ASTM A527 A36, GR50, GR65, ST-37, ST-44, ST-52, S355JR, S355J2G3, SS41, SS50, SS55 and others equivalent steel material
Surface Treatment Hot dip galvanization in accordance with Chinese standard GB/T 13912-2002 or American standard ASTM A123 or AS/NZS 4680:2006
Can be powder coated or painted according to clients' request
Wall Thickness 2~30mm
Once Forming 16m Once forming without joint
Welding Welding of cell monopole tower complies with AWS D1.1 standard.
CO2 welding or submerged arc auto methods
No fissure, scar, overlap, layer or other defects
Internal and external welding makes cell monopole tower more beautiful in shape
If customers need any other requirements of welding on cell monopole tower , we also can make adjustment ad your request
Joint Cell monopole tower is jointed with insert mode, flange mode.
Base plate Base plate is square/round/Polygon with slotted holes for anchor bolt and dimension as per client’s requirement.
Life Period More than 25 years, it is according to installing environment
