12m Manual Chain Hoist 200KN Transmission Line Stringing Tools

12m Manual Chain Hoist 200KN Transmission Line Stringing Tools

  • 12m Manual Chain Hoist 200KN Transmission Line Stringing Tools
  • 12m Manual Chain Hoist 200KN Transmission Line Stringing Tools
  • 12m Manual Chain Hoist 200KN Transmission Line Stringing Tools
12m Manual Chain Hoist 200KN Transmission Line Stringing Tools
Product Details:
Place of Origin: Ningbo,Zhejiang,China
Brand Name: Newart
Certification: ISO,CE
Model Number: 5-200KN
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: Get Latest Price
Packaging Details: Pallets and Cartons
Delivery Time: 7-10 days after deposit
Payment Terms: T/T,L/C, Western Union
Supply Ability: 1000pcs/month
Contact Now
Detailed Product Description
Product Name: Stringing Equipment Steel Wire Rope Manual Chain Hoist Usage: Tight Line
Conductor Type: Hoist Sling Type: Hand
Material: Steel Packing: Wooden Box
Application: Tight Warranty: One Year
High Light:

200KN Manual Chain Hoist

,

200KN Transmission Line Stringing Tools

,

12m Manual Chain Hoist

5M(Stringing Equipment Steel Wire Rope Manual Chain Hoist



Feature

1. Rated Load: 5~200kN
2. Chains Length: 2.5~12m
3. Steel Made
4. Min. distance between hooks: 280~1040mm

5. The lifting hoists are made of steel and equipped with mechanical brake; they are designed to facilitate and accelerate chain positioning operations.

Applicatoin
Apply to lifting parts and traction. Tigntening steel stranded wire, aluminum stranded wire and kind wires.

Specificaitons



Item No. 14282 14292 14302 14312 14321 14331 14341 14351
Rated load(KN) 5 10 15 20 30 50 100 200
Minimum distance between hooks(MM) 280 320 390 410 485 600 820 1040
Standard lifting height(M) 3
Number of lines of lifting chain(row) 1 1 1 1 2 2 4 8
Net weight(KG) 10 12 19 20 27 45.5 83 193
Item No. Lifting height(4M) 14283 14293 14303 14313 14322 14332 14342 14352
Lifting height(5M) 14284 14294 14304 14314 14323 14333 14343 14353
Lifting height(6M) 14285 14295 14305 14315 14324 14334 14344 14354
Lifting height(8M) / / / / 14325 14335 14345 14355
Lifting height(10M) / / / / 14326 14336 14346 14356
Weight of 1M chainKG 1.7 1.7 2.3 2.3 3.7 5.6 9.7 19.4

12m Manual Chain Hoist 200KN Transmission Line Stringing Tools 012m Manual Chain Hoist 200KN Transmission Line Stringing Tools 112m Manual Chain Hoist 200KN Transmission Line Stringing Tools 2
