Anti Twist Hexagon 30mm Galvanized Steel Cable Braided Pilot Wire

Anti Twist Hexagon 30mm Galvanized Steel Cable Braided Pilot Wire

  • Anti Twist Hexagon 30mm Galvanized Steel Cable Braided Pilot Wire
  • Anti Twist Hexagon 30mm Galvanized Steel Cable Braided Pilot Wire
Anti Twist Hexagon 30mm Galvanized Steel Cable Braided Pilot Wire
Product Details:
Place of Origin: Ningbo,China
Brand Name: Suntech
Certification: ISO
Model Number: steel wire rope cable
Payment & Shipping Terms:
Minimum Order Quantity: 500m
Price: Get newest price
Packaging Details: Steel Reel and Containers
Delivery Time: 10-15 days after payment
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 30000 meter per day
Contact Now
Detailed Product Description
Name: Anti Twist Steel Rope Usage: Construction Stringing
Type: Hexagon Material: Steel
Frame: Reel Surface: Galvanized With Oil
High Light:

Galvanized Steel Braided Wire

,

Hexagon 30mm Steel Braided Wire

,

Anti Twist 30mm Braided Steel Rope

High Strength Anti Twist Wire Rope , Steel Wire Rope Cable With Hexagon For Pilot Rope



Application

Galvanized steel anti-twisting braided steel wire is widely used in mining, loading, forestry and marine industries for various kinds of lifting, hoisting and pulling etc.

It is also suitable for various kinds of cable carriage, rope and belt conveyer, ropeway drawing, slope winch,

Specially braided from galvanized steel wire and widely used as pilot rope in power line stringing operation.



Features:

  1. The rotation angle is zero,and the combined rotation torque is also zero while it is bearing tension at free state .It is suitable to be used in various fields which require wire rope with no rotation .

  2. The wire rope has fine flexibility with long using life .There is no twist and no tangling up when the tension released. You can change the length and repair local damage by grafting ,which will not reduce the flexibility.

  3. Hexagon is more suitable for puller, tensioner,winch, hoisting etc .

Structural forms for wire ropes (in cross section)
1 Four-sided eight strands
2 Four-sided twelve strands
3 Six-sided twelve strands

Remarks: All kinds of non-rotating steel wire rope can be made according to the customers` requirements.



Technical Data

Item no. Normal Diameter (mm) Structure Breakage tension(kN) Standard Length (m)

Diameter of spool

(mm)

Total weight

(kgs)

YL9-12x19W 9 12 Strands 55 1000 850 294
YL10-12x19W 10 12 Strands 55 1000 850
YL11-12x19W 11 12 Strands 80 1000 1000 454
YL13-12x19W 13 12 Strands 120 1000 1100 642
YL16-12x19W 16 12 Strands 158 1000 1250 886
YL18-12x19W 18 12 Strands 210 1000 1400 1154
YL20-12x29Fi 20 12 Strands 250 1000 1400 1394
YL22-12X29Fi 22 12 Strands 320 1000 1400 1258
YL24-12x29Fi 24 12 Strands 360 800 1440 1474
YL28-12x29Fi 28 12 Strands 480 500 1600
YL30-12x29Fi 30 12 Strands 540 500 1600
YL20-18x19W 20 18 Strands 300 1000 1440 1368
YL22-18X29Fi 22 18 Strands 389 800 1440
YL24-18x29Fi 24 18 Strands 440 800 1440
YL28-18x29Fi 28 18 Strands 580 500 1600 1655
YL30-18x29Fi 30 18 Strands 658 500 1600 1900



Anti Twist Hexagon 30mm Galvanized Steel Cable Braided Pilot Wire 0
