Ningbo Suntech Power Machinery Tools Co., Ltd.
Professional Overhead Line Stringing Tools Manufacturer.
 |
| Place of Origin: | Ningbo,China |
| Brand Name: | Suntech |
| Certification: | ISO |
| Model Number: | DSJ |
| Minimum Order Quantity: | 1 PCS |
|---|---|
| Price: | Get Latest Price |
| Packaging Details: | Exported Wooden Cases |
| Delivery Time: | 7days after payment |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 200pcs per month |
| Power Source: | Electric Engine | Pulling Speed(m/min):: | 7 |
|---|---|---|---|
| Weight: | 160kg | Rubber Sheet Thickness:: | 25mm |
| Cable Diameter: | 30-180mm/30-200mm | Application: | Pulling Cable |
| High Light: | 7m/min Cable Pusher Machine,Dia30mm Cable Pusher Machine,7m/min Cable Pusher |
||
Cable Pusher Machine Cable Conveyer With Electric Engine For Laying Cable
Cable conveyer is an electric machine for laying power cable (or communication cable).It can be used with cable tractor, hoist and other cable laying machine, which can save manpower and material greatly and reduce construction cost effectively.
Usages:
DSJ series product is an electric machine for laying power cables (or communication cables).
Features:
1. The two vertical shafts drive the transmission force and gravity respectively in two directions of the cable to protect the insulation of the cable.
2. The transmission force is transmitted through the compound CAT, and adopts high strength wear-resisting rubber, which make the power force uniform and durable.
3. The machine is equipped with adjustable roller, which is very convenient.
4. The upper part of the machine can be fitted with a hinge wheel, which can be used for small power traction.
5. The machine has low mechanical noise, small temperature rise and easy maintenance.
6. Support products can be provided by user, like –DSJ series electrical control system (total control box, control box) and winding wheel etc.
Technical Data
| Model Type | DSJ-150 | DSJ-180 |
| Line pulling(KGS) | 700 | 900 |
| Pulling Speed(m/min) | 8 | 6 |
| Electric motor | 1.1KW *2 | 1.5KW * 2 |
| Oversize dimension | 950*500*400 | 1020*590*400 |
| Weight(KGS) | 150 | 180-200 |
| Cable diameter | Φ30 - 180 mm | Φ30 - 200 mm |
| Transimission | I=45 | I=60 |
| Rubber sheet thickness | 25mm | 25mm |
Application
Contact Person: Peter
Tel: 86-13958364836
